The Dahua XVR7104HE-4KL-I is a robust and versatile 4 Channel Penta-brid 4K Mini 1U Digital Video Recorder. This advanced DVR is designed to support a range of video formats, offering unparalleled flexibility and high-definition video quality. Ideal for small to medium-scale surveillance setups, it ensures comprehensive security coverage with high efficiency.
Quick Spec
| Brand | Dahua |
| Product Name | XVR7104HE-4KL-I |
| Channels | 4 |
| Video Output | 4K |
| Form Factor | Mini 1U |
Product Features
- Supports 4K video output for clear, high-definition surveillance.
- Penta-brid technology supporting five popular formats (HDCVI, AHD, TVI, CVBS, and IP).
- Intelligent video system (IVS) with advanced motion detection features.
- Remote access capability through Dahua°s mobile app and web client.
- Smart H.265+ & H.264+ dual compression for efficient storage management.
Product Applications
- Retail stores: Enhance security with detailed video footage of every corner of your store.
- Residential buildings: Monitor common areas and entrances for improved safety.
- Offices: Maintain surveillance over workspaces to prevent unauthorized access and enhance security.
Supported Options
| Accessory | Model |
| Hard Drive | Dahua HDD1TB |
| Camera | Dahua HDCVI Camera HAC-HFW1200R |
| Power Supply | Dahua PFM320D-9CH |
Compare to Similar Items
| Model | Differences |
| XVR5104HS-I2 | Does not support 4K output, fewer advanced IVS features |
| XVR4104HS-X1 | Lacks Penta-brid technology, limited remote access capabilities |
| XVR7108HE-4KL-I | Supports 8 channels, slightly larger form factor |
Get more information
For more details about the Dahua XVR7104HE-4KL-I, feel free to contact us through Live Chat or email us at sales@router-switch.com. Check Dahua XVR7104HE-4KL-I price and XVR7104HE-4KL-I datasheet, buy Dahua XVR7104HE-4KL-I DVR with the best price and fast shipping. Free Live Chat is supported.
Dahua XVR7104HE-4KL-I Specification
XVR7104HE-4KL-I Specifications |
|
| Brand | Dahua |
| Model | XVR7104HE-4KL-I |
| Video Compression | H.265+/H.265/H.264+/H.264 |
| Operating System | Embedded LINUX |
| Input | 4 channel BNC input |
| Audio Compression | G.711A, G.711U, PCM |
| Audio Input | 1 channel RCA |
| Audio Output | 1 channel RCA |
| Resolution | Up to 8MP (4K) |
| HDMI Output | 1 channel, 4K |
| VGA Output | 1 channel, 1080P |
| Internal HDD | 1 SATA port, up to 10TB capacity |
| Network Interface | 1 RJ-45 port (100M) |
| USB Interface | 2 ports (1 USB 2.0, 1 USB 3.0) |
| RS485 | 1 port, for PTZ control |
| Power Supply | DC12V/2A |
| Power Consumption | <8W (without HDD) |
| Working Temperature | -10°C ~ +55°C |
| Dimensions | 260mm°225mm°48mm |
| Net Weight | 1.16kg (without HDD) |
