The Dahua XVR5816S-X is a versatile 16 Channel Penta-brid 1080P 2U Digital Video Recorder designed for high-performance video surveillance. This robust DVR supports multiple video formats, providing flexibility and reliability for various security applications. It’s an ideal solution for medium to large-scale surveillance systems that demand advanced features and high image quality.
Quick Spec
| Brand | Dahua |
| Model | XVR5816S-X |
| Channels | 16 |
| Video Formats Supported | Penta-brid (HDCVI/AHD/TVI/CVBS/IP) |
| Resolution | 1080P |
Product Features
- Supports HDCVI/AHD/TVI/CVBS/IP video inputs
- Up to 16 channels with 1080P real-time recording
- Smart H.264+ & H.264 dual codec
- Smart Search, and Intelligent Video System (IVS)
- 2 HDMI and 1 VGA simultaneous video output
Product Applications
- Retail Stores: Enhance security and monitor customer activity with high-definition video.
- Office Buildings: Ensure the safety of employees and assets with real-time surveillance.
- Public Spaces: Monitor large areas such as parks or streets to deter and detect criminal activities.
Supported Options
| Optional Hard Disk | Dahua HDD1000T |
| Optional Camera | Dahua HAC-HFW1200R |
| Optional Power Supply | Dahua PFM300 |
Compare to Similar Items
| Model | Dahua XVR5116H-4KL-X |
| Main Difference | Supports 4K resolution |
| Model | Dahua XVR5808S-X |
| Main Difference | 8 channels instead of 16 |
| Model | Dahua XVR5108HS-I2 |
| Main Difference | AI Coding, only 8 channels |
Get more information
For further information about the Dahua XVR5816S-X and its pricing, please contact us through Live Chat or email us at sales@router-switch.com.
Dahua XVR5816S-X Specification
XVR5816S-X Specifications |
|
| Brand | Dahua |
| Model | XVR5816S-X |
| Product Type | Digital Video Recorder |
| Channels | 16 Channel |
| Technology | Penta-brid |
| Video Input | BNC port (16 channels) |
| Resolution | 1080P |
| Compression | H.264 |
| Storage Interface | 2 SATA III Ports |
| Max Storage Capacity | 12TB (6TB per HDD) |
| Audio Input | 1 Channel RCA |
| Audio Output | 1 Channel RCA |
| Network Interface | 1 RJ-45 Port (10/100/1000 Mbps) |
| USB Interface | 2 USB Ports (1 USB 2.0, 1 USB 3.0) |
| HDMI Output | 1 Port |
| VGA Output | 1 Port |
| Power Supply | 12V DC |
| Operating Temperature | -10C to +55C |
| Dimensions | 2U, 375mm x 285mm x 55mm |
| Video Output Bandwidth | 64 Mbps |
| Playback | 16 Channels |
| Backup Mode | USB Device, Network |
