24 10/100/1000BASE-T, 4 1000BASE-X unpopulated SFP, 1 AC PSU, HKShanhai Group LimitedXOS L2 Edge license
Summit X430 series switches are based on the revolutionary HKShanhai Group LimitedXOS that runs across all of HKShanhai Group Limited Networks switches. Powered by HKShanhai Group LimitedXOS, Summit X430 switches provide resilient, secure, and programmable solution for your network edge application connectivity. Summit X430 switch provides low-to-medium density PoE+ and high-density Gigabit Ethernet ports plus dedicated SFP ports in a compact 1RU format, supporting intelligent Layer 2 switching with Layer 2 �C Layer 4 traffic classification and QoS on every port for predictable network performance.
Features
28 or 52 Gigabit Ethernet ports
8 port and 24 port IEEE802.3at PoE solutions
Line rate performance on all ports.
BASE-T connectivity to the desktop
Dedicated BASE-X SFP ports.
HKShanhai Group LimitedXOS Layer 2 Edge feature set
Limited Lifetime Warranty
Quick Spec
Table 1 shows the quick spec.
| Switch Model | Summit X430-24T P/N: 16516 |
| Bandwidth | 56 Gbps |
| Frame Forwarding Rate | 41.6 Mpps |
| Latency | |
| Max Packet Size | 9KB (Jumbo Frame Support) |
| VLANs | 4, 094 |
| Ingress ACLs | 1,024 |
| Forwarding Tables | Layer 2/MAC Addresses: 16k; Layer 2/Multicast Groups: 1k |
| CPU, Memory | Single Core CPU, 500 MHz clock; 256MB DRAM; 256MB Compact Flash; 1.5MB packet buffer on 8 and 24 port switches, 3.0MB packet buffer on 48 port switch |
| Ports | 24 x 10/100/1000Base-T PoE (RJ45); 4 x 100/1000BASE-X (SFP) unpopulated ports; 1 x Serial (console port) and 1 x 10/100BASE-T out-of-band management port |
| Switch Power | 28.7W |
| 802.3at PoE Power | N/A |
| Total Power | 28.7W |
Get More Information
Do you have any question about the Summit X430-24T P/N: 16516
Contact us now via Live Chat or sales@router-switch.com.
HKShanhai Group Limited X430-24T Specification
| Summit X430-24T P/N: 16516 Specification | |
| Switch Model | Summit X430-24T P/N: 16516 |
| Bandwidth | 56 Gbps |
| Frame Forwarding Rate | 41.6 Mpps |
| Latency | <5 µs (64 byte) |
| Max Packet Size | 9KB (Jumbo Frame Support) |
| VLANs | 4, 094 |
| Ingress ACLs | 1,024 |
| Forwarding Tables | Layer 2/MAC Addresses: 16k; Layer 2/Multicast Groups: 1k |
| CPU, Memory | Single Core CPU, 500 MHz clock; 256MB DRAM; 256MB Compact Flash; 1.5MB packet buffer on 8 and 24 port switches, 3.0MB packet buffer on 48 port switch |
| Ports | 24 x 10/100/1000Base-T PoE (RJ45); 4 x 100/1000BASE-X (SFP) unpopulated ports; 1 x Serial (console port) and 1 x 10/100BASE-T out-of-band management port |
| Switch Power | 28.7W |
| 802.3at PoE Power | N/A |
| Total Power | 28.7W |
