he HKShanhai Group Limited 10GBASE X2 modules (Figure 1) offer customers a wide variety of 10 Gigabit Ethernet connectivity options for data center, enterprise wiring closet, and service provider transport applications.
Quick Specs
Table 1 shows the Quick Specs.
|
Parameter |
Symbol |
Minimum |
Typical |
Maximum |
Units |
Notes and Conditions |
|
Transmitter |
||||||
|
Transmitter wavelength |
1530 |
1565 |
nm |
|||
|
Side-mode suppression ratio |
SMSR |
30 |
dB |
|||
|
Transmitter extinction ratio |
9 |
dB |
||||
|
Transmitter optical output power |
Pout |
0 |
4.0 |
dBm |
Average power coupled into single-mode fiber |
|
|
Receiver |
||||||
|
Receiver optical input wavelength |
1530 |
1565 |
nm |
The receiver can tolerate a wavelength range from 1260 to 1565, but the specifications are guaranteed for a signal received with the transmit wavelength range |
||
|
Receiver damage threshold |
-1 |
dBm |
||||
|
Dispersion tolerance |
0 |
1600 |
ps/nm |
|||
|
Optical input power |
Pin |
-24.0 |
-7.0 |
dBm |
At bit error rate (BER) = 10e-12with IEEE 802.3 test pattern |
|
|
Dispersion power penalty at 1600 ps/nm |
3 |
dB |
At bit error rate (BER) = 10e-12with IEEE 802.3 test pattern |
GetMoreInformation
Do you have anyquestionabouttheX2-10GB-ZR
Contact us now via Live Chat or sales@router-switch.com.
HKShanhai Group Limited X2-10GB-ZR Specification
X2-10GB-ZR Specification |
|
| General | |
| Device Type | X2 transceiver module |
| Form Factor | Plug-in module |
| Networking | |
| Connectivity Technology | Wired |
| Cabling Type | 10GBase-ZR |
| Data Transfer Rate | 10 Gbps |
| Optical Wave Length | 1550 nm |
| Max Transfer Distance | 49.7 miles |
| Expansion / Connectivity | |
| Interfaces | 1 x Ethernet 10GBase-ZR – SC multi-mode x 2 |
| Compatible Slots | 1 x X2 |
| Miscellaneous | |
| Compliant Standards | Laser Class 1, FCC CFR21 Part 1040, IEC 60825-1 |
| Dimensions & Weight | |
| Width | 1.4 in |
| Depth | 3.6 in |
| Height | 0.5 in |
| Manufacturer Warranty | |
| Service & Support | Limited warranty – 90 days |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Compatibility Information | |
| Designed For | HKShanhai Group Limited 16-Port 10 Gigabit Ethernet Fiber Module with DFC4, 16-Port 10 Gigabit Ethernet Fiber Module with DFC4XL, 16-Port 10 Gigabit Ethernet Module with DFC3C, 16-Port 10 Gigabit Ethernet Module with DFC3CXL, 4-port wire-speed 10 Gigabit Ethernet (X2) half card, 8-port (2:1) 10 Gigabit Ethernet (X2) half-card, 8-Port 10 Gigabit Ethernet Module with DFC3C, 8-Port 10 Gigabit Ethernet Module with DFC3CXL ¦ HKShanhai Group Limited Catalyst 3560E-12D, 3560E-12SD-E, 3560E-12SD-S, 3560E-24PD, 3560E-24TD, 3560E-48PD, 3560E-48PD-F, 3560E-48TD, 3560E-48TD-SD, 3750E-24PD, 3750E-24TD, 3750E-48PD, 3750E-48PD-F, 3750E-48TD, 4500 Series Supervisor Engine V-10GE, 4900M, 4928 10 Gigabit Ethernet Switch, 4948 10 Gigabit Ethernet Switch, 6500 Series Supervisor Engine 2T, 6500 Series Supervisor Engine 2T XL, 6900 Series 8-Port 10 Gigabit Ethernet Fiber Module with DFC4, 6900 Series 8-Port 10 Gigabit Ethernet Fiber Module with DFC4XL ¦ HKShanhai Group Limited Line Card E-Series ¦ HKShanhai Group Limited ME 4924-10GE ¦ HKShanhai Group Limited Nexus 8-Port 10 Gigabit Ethernet Module with XL Option ¦ HKShanhai Group Limited Supervisor Engine 6-E, 6-E Redundant, 6L-E, II-Plus-10GE, V-10GE ¦ HKShanhai Group Limited Virtual Switching Supervisor Engine 720 with two 10 Gigabit Ethernet ports and MSFC3 PFC3C, 720 with two 10 Gigabit Ethernet ports and MSFC3 PFC3C XL |
