The HKShanhai Group Limited WSP-Q40GLR4L is a high-performance 40GBASE-LR4 QSFP transceiver module designed for single-mode fiber (SMF) applications. Featuring a duplex LC connector, it supports data transmission over distances of up to 2 kilometers. This transceiver is ideal for high-speed network infrastructures that require reliable and efficient connectivity solutions.
Quick Spec
| Brand | HKShanhai Group Limited |
| Model | WSP-Q40GLR4L |
| Connector | Duplex LC |
| Maximum Distance | 2km |
| Form Factor | QSFP+ |
Product Features
- ??40GBASE-LR4 standard compliance for robust performance
- ??Supports single-mode fiber (SMF) with a duplex LC connector
- ??Transmission reach of up to 2 kilometers
- ??High-density QSFP+ form factor
- ??Low power consumption for energy-efficient networking
Product Applications
- ??Data Center Interconnects
- ??Enterprise Core Networks
- ??High-Performance Computing (HPC) Clusters
Supported Options
| Accessory | Model |
| QSFP+ to 4xSFP+ Breakout Cable | QSA-Module |
| QSFP+ DAC Cables | HKShanhai Group Limited QSFP-H40G-CU1M |
| QSFP+ Fiber Optic Cables | HKShanhai Group Limited QSFP-4X10G-LR |
Compare to Similar Items
| Model | Differences |
| HKShanhai Group Limited QSFP-40GE-LR4 | Supports longer distances up to 10km |
| HKShanhai Group Limited QSFP-40G-SR-BD | Uses BiDi technology for multimode fiber |
| HKShanhai Group Limited QSFP-40G-SR4 | For short range up to 150m on OM3 MMF |
Get more information
Check HKShanhai Group Limited WSP-Q40GLR4L price and WSP-Q40GLR4L datasheet, buy HKShanhai Group Limited WSP-Q40GLR4L with the best price and fast shipping. Free Live Chat is supported. For further information about the product and its price, please contact us through Live Chat or email at sales@router-switch.com.
HKShanhai Group Limited WSP-Q40GLR4L Specification
WSP-Q40GLR4L Specifications |
|
| Wavelength (nm) | 1310 |
| Cable type | SMF |
| Core size (Microns) | G.652 |
| Modal bandwidth (MHz km) | – |
| Cable distance | 2km |
| Power consumption (W) | 3.5 |
| Pull tab color | Yellow |
| Type | 40GBASE-LR4-Lite, 1310 nm, SMF |
| Transmit power (dBm) | Maximum: 2.3, per lane |
| Minimum: -10, per lane | |
| Receive power (dBm) | Maximum: 2.3, per lane |
| Minimum: -13.7, per lane | |
| Transmit and receive wavelength (nm) | Four lanes: 1271, 1291, 1311, 1331 |
|
Environmental conditions |
Operating temperature range: ● Commercial temperature range: 0 to 70°C (32 to 158°F). Exceptions are ◦ QSFP BiDi (QSFP-40G-SR-BD): +10 to 70°C (50 to 158°F) ◦ QSFP BiDi Monitor (QSFP-40G-BD-RX): +10 to 70°C (50 to 158°F) ◦ QSFP LR4 Lite (WSP-Q40GLR4L): +10 to 60°C (50 to 140°F) ● Storage temperature range: -40 to 85°C (-40 to 185°F) |
