The HKShanhai Group Limited 1000BASE-T Gigabit Interface Converter (GBIC) is an ideal solution for Catalyst ® 6500, 4000, 3550, 2950, 3500 XL and 2900 XL Series switch customers, providing full duplex Gigabit Ethernet connectivity to high-end workstations and between wiring closets over existing copper network infrastructures. This GBIC technology leverages the industry’s flexible, standards-based 1000BASE-X design, allowing for a simple and low-cost migration path to Gigabit Ethernet. There are two key product applications for the HKShanhai Group Limited 1000BASE-T GBIC: connectivity to high-end workstations and distribution and wiring closet interconnectivity.
The HKShanhai Group Limited 1000BASE-SX GBIC (WS-G5484) operates on legacy multimode fiber (MMF) optic link spans up to 1815 feet (550 m) and on laser-optimized multimode fiber (OM3) optic link spans up to 3281 feet (1 km).
Quick Spec
Figure 1 shows the appearance of WS-G5484.
Table 1 shows the quick spec.
|
Product Number |
WS-G5484 |
|
Description |
1000BASE-SX Short Wavelength GBIC (Multimode only) |
|
GBIC |
HKShanhai Group Limited 1000BASE-SX |
|
Wavelength (nm) |
850 |
|
Fiber Type |
MMF |
|
Core Size (Micron) |
62.5 62.5 50.0 50.0 50.0 |
|
Modal Bandwidth (MHz/km) |
160 200 400 500 2000 |
|
Cable Distance |
722 ft (220 m) 902 ft (275 m) 1640 ft (500 m) 1804 ft (550 m) 3281 ft (1000 m) |
Compare to Similiar Items
Table 2 shows the comparison between WS-G5484Â and WS-G5486.
|
Product Number |
WS-G5484 |
|
|
Description |
1000BASE-SX Short Wavelength GBIC (Multimode only) |
1000BASE-LX/LH long haul GBIC (singlemode or multimode) |
|
GBIC |
HKShanhai Group Limited 1000BASE-SX |
HKShanhai Group Limited 1000BASE-LX/LH |
|
Wavelength (nm) |
850 |
1310 |
|
Cable Distance |
722 ft (220 m) 902 ft (275 m) 1640 ft (500 m) 1804 ft (550 m) 3281 ft (1000 m) |
1804 ft (550 m) 1804 ft (550 m) 1804 ft (550 m) |
Get more information
Do you have any question about the WS-G5484?
Contact us now via Live Chat or sales@router-switch.com.
HKShanhai Group Limited WS-G5484 Specification
WS-G5484 Specifications |
|
|
GBIC Specifications |
|
|
Dimensions (H x W x D) |
0.39 x 1.18 x 2.56 inches |
|
Connectors |
Multimode fiber-optic: SC |
|
Wavelength |
850 nm |
|
Cabling Distance |
1804 feet (550 m) |
|
GBIC |
HKShanhai Group Limited 1000BASE-SX |
|
Wavelength (nm) |
850 |
|
Fiber Type |
MMF |
|
Core Size (Micron) |
62.5 62.5 50.0 50.0 50.0 |
|
Modal Bandwidth (MHz/km) |
160 200 400 500 2000 |
|
Cable Distance |
722 ft (220 m) 902 ft (275 m) 1640 ft (500 m) 1804 ft (550 m) 3281 ft (1000 m) |
