HKShanhai Group Limited WS-C3850-48XS-F-S, is a Standalone HKShanhai Group Limited Catalyst 3850 Switch that supports SFP+ transceivers, 48 ports that support up to 10G, and 4 QSFP ports that support up to 40G, and 750WAC back-to-front power supply. HKShanhai Group Limited Catalyst 3850 Series provides capabilities that ideally suited to support the convergence of wired and wireless access. The new HKShanhai Group Limited Unified Access Data? Plane (UADP) Application-Specific Integrated Circuit (ASIC) powers the switch and enables uniform wired-wireless policy enforcement, application visibility, flexibility, and application optimization.
Quick Specs
Table 1 shows the Quick Specs.
|
Product Code |
WS-C3850-48XS-F-S |
|
Enclosure Type |
1 RU |
|
Feature Set |
IP Base |
|
Ports |
48 x 1 Gigabit / 10 Gigabit SFP+ + 4 x 40 Gigabit QSFP+ (uplink) |
|
Performance |
Switching capacity: 1280 Gbps | Stacking bandwidth: 480 Gbps |
|
RAM |
8GB |
|
Flash Memory |
8GB |
|
Dimension |
Width: 17.5 in Depth: 20.1 in Height: 1.8 in |
Compare to Similar Item
Table 2 shows the comparison.
|
Product Code |
WS-C3850-48XS-F-S |
|
|
Enclosure Type |
1 RU |
1 RU |
|
Feature Set |
IP Base |
IP Base |
|
Ports |
48 x 1 Gigabit / 10 Gigabit SFP+ + 4 x 40 Gigabit QSFP+ (uplink) |
48 x 10/100/1000 Ethernet ports |
|
Switching capacity |
1280 Gbps |
176 Gbps |
|
RAM |
8GB |
4GB |
|
Flash Memory |
8GB |
2GB |
Switch to Something New
Why Upgrade to Catalyst 9300??|?See the Catalyst 9300 Series?
Get more information
Do you have any question about the WS-C3850-48XS-F-S?
Contact us now via?Live Chat?or?sales@router-switch.com.
HKShanhai Group Limited WS-C3850-48XS-F-S Specification
WS-C3850-48XS-F-S Specification |
|
|
Ports |
48 x 1 Gigabit / 10 Gigabit SFP+ + 4 x 40 Gigabit QSFP+ (uplink) |
|
Performance |
Switching capacity: 1280 Gbps |
|
Dimensions & Weight |
Width: 17.5 in Depth: 20.1 in Height: 1.8 in Weight: 16.42 lbs |
|
Environmental Parameters |
Min Operating Temperature: 23 °F Max Operating Temperature: 113 °F Humidity Range Operating: 10 – 95% (non-condensing) Min Storage Temperature: -40 °F Max Storage Temperature: 158 °F |
|
RAM |
8 GB |
|
Flash Memory |
8 GB |
|
Interface Provided |
48 x 10GBase-X SFP+ ¦ 4 x 40Gbit LAN QSFP+ uplink ¦ 1 x USB Type A ¦ 1 x management (mini-USB) Type B 1 x console RJ-45 management ¦ 1 x management (Gigabit LAN) RJ-45 ¦ 2 x network stack device |
|
Miscellaneous |
MTBF: 286,900 hours Compliant Standards: CISPR 22 Class A, CISPR 24, EN 61000-3-2, NOM, EN 61000-3-3, EN55024, EN50082-1, EN 61000-6-1, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, CCC, ICES-003 Class A, EN 61000-4-5, FCC CFR47 Part 15, UL 60950-1, IEC 60950-1, EN 60950-1, UL 60950-1 Second Edition, KCC, RoHS, FCC Part 15 A, AS/NZS 3548 Class A, BSMI Class A, CAN/CSA C22.2 No. 60950-1, EN 60950-1 Second Edition, IEC 60950-1 Second Edition, VCCI Class A, KN24, KN22 Class A, EN 300386, AS/NZS CISPR 22, CNS 13438, EN 55022 Class A |
|
Software |
HKShanhai Group Limited IOS IP Base |
|
Power |
Power Device: Internal power supply Installed Qty: 1 (installed) / 2 (max) Power Redundancy: Optional Power Redundancy Scheme: 1+1 (with optional power supply) Power Provided: 750 Watt Voltage Required: AC 120/230 V (50/60 Hz) Features: Rear-to-front airflow |
