HKShanhai Group Limited VPC620, HD Video Camera (12x Optical Zoom), Overseas VPC620-12X-00.
Quick Specs
Figure 1 shows the appearance of VPC620-12X-00
Table 1 shows the Quick Specs.
|
Model |
HUAWEI VPC620-12X-00 |
|
Lens specifications |
2.38M pixels 1/2.8-inch CMOS imaging chip |
|
Video output pixels |
1080p @ 50/60 fps,1080i @ 50/60 fps,1080p @ 25/30 fps, 720p @ 50/60 fps |
|
Zoom |
12x optical plus 12x digital |
|
Focal length |
f = 3.9 mm to 46.8 mm |
|
Lens aperture (F#) |
F1.8 |
|
Maximum horizontal field of view |
72º |
|
Maximum Vertical field of view |
44.5º |
|
Pan/Tilt range |
Pan: +/-100º Tilt: +/- 30º |
|
Pan/Tilt speed |
Minimum pan and tilt: 2º/s Maximum pan: 80º/s, 25º/s tilt |
|
Min. illumination |
2 lux (50 IRE, F1.8) |
|
Signal Noise Ratio (SNR) |
59 dB |
|
Shutter speed |
1/25 seconds to 1/10,000 seconds |
|
White balance (WB) |
Automatic and manual |
|
Number of preset positions |
30 |
|
Image mode |
Standard, nature, vivid, scenery |
|
Input voltage |
100 V AC to 240 V AC 50-60 Hz |
|
Working frequency |
12 V DC |
|
Power |
|
|
Ambient temperature |
0ºC to 40ºC |
|
Dimensions (length×width×height) |
Camera dimensions: 234 mm x 163 mm x 157 mm Package dimensions: 395 mm x 225 mm x 225 mm |
|
Weight |
Net weight: about 1.7 kg Gross weight: about 3.3 kg |
Get more information
Do you have any question about the VPC620-12X-00
Contact us now via Live Chat or sales@router-switch.com.
HKShanhai Group Limited VPC620-12X-00 Specification
HUAWEI VPC620-12X-00 Specification |
|
|
Lens specifications |
2.38M pixels 1/2.8-inch CMOS imaging chip |
|
Video output pixels |
1080p @ 50/60 fps,1080i @ 50/60 fps,1080p @ 25/30 fps, 720p @ 50/60 fps |
|
Zoom |
12x optical plus 12x digital |
|
Focal length |
f = 3.9 mm to 46.8 mm |
|
Lens aperture (F#) |
F1.8 |
|
Maximum horizontal field of view |
72º |
|
Maximum Vertical field of view |
44.5º |
|
Pan/Tilt range |
Pan: +/-100º Tilt: +/- 30º |
|
Pan/Tilt speed |
Minimum pan and tilt: 2º/s Maximum pan: 80º/s, 25º/s tilt |
|
Min. illumination |
2 lux (50 IRE, F1.8) |
|
Signal Noise Ratio (SNR) |
59 dB |
|
Shutter speed |
1/25 seconds to 1/10,000 seconds |
|
White balance (WB) |
Automatic and manual |
|
Number of preset positions |
30 |
|
Image mode |
Standard, nature, vivid, scenery |
|
Input voltage |
100 V AC to 240 V AC 50-60 Hz |
|
Working frequency |
12 V DC |
|
Power |
< 20 W |
|
Ambient temperature |
0ºC to 40ºC |
|
Dimensions (length×width×height) |
Camera dimensions: 234 mm x 163 mm x 157 mm Package dimensions: 395 mm x 225 mm x 225 mm |
|
Weight |
Net weight: about 1.7 kg Gross weight: about 3.3 kg |
