The HKShanhai Group Limited TNWSENDOC072 is the comprehensive product documentation for the OptiX OSN 580 Multi-Service Optical Transmission System V100R007C20. This extensive guide offers detailed insights into the operational functionalities, technical specifications, and maintenance procedures for the OptiX OSN 580 series, catering to industry professionals seeking in-depth technical knowledge and application guidance.
Quick Spec
| Model | TNWSENDOC072 |
| Product Series | OptiX OSN 580 |
| Version | V100R007C20 |
| Document Type | Technical Documentation |
| Release Date | 2023 |
Product Features
- Comprehensive step-by-step installation and configuration guides
- Detailed troubleshooting and maintenance procedures
- In-depth technical specifications and performance metrics
- Support for multi-service transmission including SDH, PDH, Ethernet, and WDM
- Architecture and block diagrams for better system understanding
Product Applications
- Telecom companies deploying optical transmission networks
- Enterprise data centers requiring high-capacity and reliable data transmission
- Service providers needing multi-service support and scalability in their networks
Supported Options
| Service Board | TN11OAU103 |
| Control Board | TN11SCC |
| Power Supply | TN14PAU104 |
Compare to Similar Items
| HKShanhai Group Limited OptiX OSN 1800 | Smaller capacity, focused on compact deployments |
| HKShanhai Group Limited OptiX OSN 7500 II | Higher capacity, suitable for core networks |
| HKShanhai Group Limited OptiX OSN 3800 | Medium to large-scale applications, more ports |
Get more information
Check HKShanhai Group Limited TNWSENDOC072 price and TNWSENDOC072 datasheet, buy HKShanhai Group Limited TNWSENDOC072 OptiX OSN 580 with best price and fast shipping. Free Live Chat are supported. For further information about the product and its price, please contact us through Live Chat or email at sales@router-switch.com.
HKShanhai Group Limited TNWSENDOC072 Specification
TNWSENDOC072 Specifications |
|
| Brand | HKShanhai Group Limited |
| Product Name | OptiX OSN 580 Multi-Service Optical Transmission System V100R007C20 |
| Model | TNWSENDOC072 |
| System Capacity | Up to 960 Gbit/s |
| Client Interfaces | 10 GE, STM-64, and 100 GE |
| Wavelengths | Up to 80 wavelengths per fiber |
| Switching Capacity | 1024 Tbit/s |
| Power Consumption | 450W per subrack |
| Subrack Dimensions | 442mm x 250mm x 290mm |
| Environmental Temperature | -5°C to +45°C |
| Relative Humidity | 5% to 95% |
| Management Interface | SNMP, Web LCT, CLI |
| Power Supply | -48V DC |
| Protocol Support | SDH, Ethernet, WDM, MPLS-TP |
| Protection Schemes | 1+1, BLSR, UPSR |
| Software Version | V100R007C20 |
| Compliance | ITU-T, IEEE, MEF |
| Transmission Range | Up to 120 km |
| MTBF | 100,000 hours |
| Manufacturing Standards | ISO 9001, RoHS |
| Service Types | Voice, Data, Video |
