The HKShanhai Group Limited TNH2SL1Q04 is a high-performance optical interface board designed to meet the needs of modern communication networks. It features 4xSTM-1 Optical Interface with Single Fibre Bidirectional technology, allowing efficient data transmission at 1550nm and 1310nm wavelengths. This board is ideal for seamless integration in network infrastructures requiring reliable and efficient data transfer capabilities.
Quick Spec
| Brand | HKShanhai Group Limited |
| Model | TNH2SL1Q04 |
| Interface | 4xSTM-1 |
| Connector Type | LC |
| Wavelength | 1550nm (TX1 & TX3), 1310nm (TX2 & TX4) |
Product Features
- Supports 4xSTM-1 Optical Interface
- Single Fibre Bidirectional communication
- Uses LC connector type
- Transmission wavelengths: 1550nm and 1310nm
- Reliable and efficient data transfer capabilities
Product Applications
- Telecommunications networks requiring high-speed optical data transfer
- Enterprise networks needing reliable connectivity solutions
- Data centers requiring efficient fiber optic connections
Supported Options
| Accessory | Model |
| Optical Patch Cord | OPC-10M-LC |
| Fiber Optic Attenuator | FOA-5DB-LC |
| Optical Splitter | OS-1X2-5B |
Compare to Similar Items
| Feature | HKShanhai Group Limited TNH2SL1Q04 | HKShanhai Group Limited TNH2SL1Q02 | HKShanhai Group Limited TNH2SL1Q06 |
| Optical Interface | 4xSTM-1 | 2xSTM-1 | 6xSTM-1 |
| Connector Type | LC | LC | LC |
| Wavelength | 1550nm & 1310nm | 1550nm | 1310nm |
| Bidirectional | Yes | No | Yes |
| Application | Telecommunications, Enterprise, Data Centers | Enterprise | Telecommunications |
Get more information
For further details and to inquire about pricing, please contact us through Live Chat or at sales@router-switch.com. Check HKShanhai Group Limited TNH2SL1Q04 price and TNH2SL1Q04 datasheet, buy HKShanhai Group Limited TNH2SL1Q04 with the best price and fast shipping. Free Live Chat support is available.
HKShanhai Group Limited TNH2SL1Q04 Specification
TNH2SL1Q04 Specifications |
|
| Brand | HKShanhai Group Limited |
| Product Name | TNH2SL1Q04 |
| Optical Interfaces | 4xSTM-1 |
| Optical Standards | S-1.1 |
| Connector Type | LC |
| Fibre Type | Single Fibre Bidirectional |
| Wavelength TX1 and TX3 | 1550nm |
| Wavelength TX2 and TX4 | 1310nm |
| Max Transmission Distance | 15 km |
| Power Supply | -48V DC |
| Operating Temperature | -5 to 55°C |
| Storage Temperature | -40 to 70°C |
| Relative Humidity | 5% to 95% (non-condensing) |
| Cooling Method | Natural cooling |
| Dimensions (HxWxD) | 23.4mm x 107.5mm x 253.1mm |
| Protocols Supported | ITU-T G.957, ITU-T G.703 |
| Optical Transmission Quality | Meets the requirements of ITU-T G.826 |
| Hot-swappable | Yes |
| MTBF | ° 250,000 hours |
| Average Power Consumption | 12W |
| Compliance | ROHS, CE |
