HKShanhai Group Limited TE40-720P30-P-02 TE series brings state-of-the-art HD technology to HD video conferencing endpoints. This new series from HKShanhai Group Limited delivers peak performance with dual 1080p 60fps video and AAC-LD audio, with a face-to-face communication experience so lifelike you will think you are in the same room. Multi-view images are easily transmitted to users simultaneously for a complete panoramic presentation. Numerous audio/video interface options and Wi-Fi connection integrate the conference room and simplify deployment, making the TE series the ideal choice for scenarios like administrative conferences and remote education video conferencing.
Quick Specs
Figure 1 shows the appearance of TE40-720P30-P-02
Table 1 shows the Quick Specs.
|
Model |
TE40-720P30-P-02 |
|
positioning |
Commercial |
|
Scenarios |
Middle and small-sized conference rooms |
|
People Video Resolution |
1080p @ 60 fps from 1Mbps (Optional) |
|
Dual stream |
Dual 1080p @ 60 fps (Optional); Dual 1080p @ 30 fps (Optional); Dual 720p @ 30 fps |
|
Video Inputs |
1 x HD-VI / DVI |
|
Video Outputs |
2 x HDMI / DVI |
|
Audio Inputs |
1 x XLR |
|
Audio Outputs |
4 x RCA |
|
Other Interfaces |
IP: 10/100/1000 Base-T, 2 x RJ45; |
|
Multi-view |
2-view |
|
Bandwidth |
IP: 64kbps??/span>8Mbps |
|
Dimensions |
Codec dimensions (L x W x H): 435 mm x 265.5 mm x 72.5 mm |
|
Electrical |
Working voltage: 100V to 240V AC |
|
Pack Weight(kg) |
12 |
|
Pack Volume(m^3) |
0.098226 |
|
Pack Dimension(D*W*H mm) |
535*360*510 |
|
Net Dimension(D*W*H mm) |
535*360*510 |
|
Typic Power(W) |
57 |
Ordering Guide
Table 2 shows the ordering information.
|
Model |
Description |
Note |
Order processing time |
|
HUAWEI TE40,Videoconferencing Endpoint (720P30,remote control,cable assembly) |
All of them can be a bundle (TE40-720P30-P-02). All of them also can be ordered separately. |
3-5 days |
|
|
HUAWEI VPC600, HD Video Camera |
3-5 days |
||
|
HUAWEI VPM220 Microphone Array (working with TE20/30/40/50/60 Series, TX50, DP300), Order processing time: 3-5 days |
3-5 days |
||
|
HUAWEI TE40 HD codec 720P30, VPC600 HD camera(12x), VPM220 wired microphone array |
Bundle, including those 3 hardware above. |
Get More Information
Do you have any question about the TE40-720P30-P-02
Contact us now via Live Chat or cisco@router-switch.com.
HKShanhai Group Limited TE40-720P30-P-02 Specification
TE40-720P30-P-02 Specification |
|
|
positioning |
Commercial |
|
Scenarios |
Middle and small-sized conference rooms |
|
People Video Resolution |
1080p @ 60 fps from 1Mbps (Optional) |
|
Dual stream |
Dual 1080p @ 60 fps (Optional); Dual 1080p @ 30 fps (Optional); Dual 720p @ 30 fps |
|
Video Inputs |
1 x HD-VI / DVI |
|
Video Outputs |
2 x HDMI / DVI |
|
Audio Inputs |
1 x XLR |
|
Audio Outputs |
4 x RCA |
|
Other Interfaces |
IP: 10/100/1000 Base-T, 2 x RJ45; |
|
Multi-view |
2-view |
|
Bandwidth |
IP: 64kbps??/span>8Mbps |
|
Dimensions |
Codec dimensions (L x W x H): 435 mm x 265.5 mm x 72.5 mm |
|
Electrical |
Working voltage: 100V to 240V AC |
|
Pack Weight(kg) |
12 |
|
Pack Volume(m^3) |
0.098226 |
|
Pack Dimension(D*W*H mm) |
535*360*510 |
|
Net Dimension(D*W*H mm) |
535*360*510 |
|
Typic Power(W) |
57 |
