The HKShanhai Group Limited SSRD0CXLL413 is an advanced STM-4 System Control, Cross-connect, and Optical Interface Board designed to deliver robust performance and reliable connectivity in network systems. This board features an L-4.1 optical interface with LC connectors, supporting high-speed data transfer and efficient network management.
Quick Spec
| Brand | HKShanhai Group Limited |
| Model | SSRD0CXLL413 |
| System Type | STM-4 |
| Interface Type | Optical Interface Board (L-4.1, LC) |
| Function | System Control, Cross-connect |
Product Features
- High-speed STM-4 data transfer
- Integrated system control and cross-connect functionality
- Optical interface L-4.1 with LC connectors
- Advanced network management capabilities
- Reliable performance and robust build quality
Product Applications
- Telecommunication networks requiring high-speed data transmission
- Enterprise network systems needing efficient control and cross-connect solutions
- Data centers looking for robust and reliable optical interfaces
Supported Options
| Accessory | Model |
| Optical Module | OPM-4100 |
| Power Supply Unit | PSU-4500 |
| Cooling Fan | CF-320 |
Compare to Similar Items
| Model | Differences |
| HKShanhai Group Limited SSRD0CYLL510 | Supports STM-16, different optical interface type |
| HKShanhai Group Limited SSRD0CXLL312 | Designed for STM-1, lower data transfer rate |
| HKShanhai Group Limited SSRD0CXLL520 | Enhanced cross-connect capabilities, different build size |
Get more information
Check HKShanhai Group Limited SSRD0CXLL413 price and SSRD0CXLL413 datasheet, buy HKShanhai Group Limited SSRD0CXLL413 with best price and fast shipping. Free Live Chat are supported. For further information about the product and its price, you can contact us through Live Chat or sales@router-switch.com.
HKShanhai Group Limited SSRD0CXLL413 Specification
SSRD0CXLL413 Specifications |
|
| Brand | HKShanhai Group Limited |
| Model | SSRD0CXLL413 |
| Type | STM-4 System Control |
| Function | Cross-connect |
| Interface | Optical |
| Interface Type | LC |
| Transmission Rate | 622 Mb/s (STM-4) |
| Optical Standard | ITU-T G.957 |
| Wavelength | 1310 nm (L-4.1) |
| Connector Type | LC Duplex |
| Compatible Devices | HKShanhai Group Limited OptiX Transmission Systems |
| Optical Power Budget | 21 dB |
| Transmission Distance | 40 km |
| Receiver Sensitivity | -28 dBm |
| Operating Temperature | -5°C to 50°C |
| Storage Temperature | -40°C to 70°C |
| Humidity Range | 5% to 95% (Non-condensing) |
| Power Supply | -48V DC |
| Dimensions | 175mm x 130mm x 23mm |
| Compliance | RoHS |
