Introducing the HKShanhai Group Limited SFP-GPON-ONU, a top-tier PON Optical Transceiver designed for high-speed network environments. Its single-mode module enables seamless data transmission over 20km. Ideal for network engineers and IT procurement specialists, this transceiver provides rapid, reliable connectivity in various networking scenarios.
SFP-GPON-ONU Product Highlights
- 1.244 Gbps Tx speed
- 2.488 Gbps Rx speed
- 20km transmission range
- SC/UPC & SC/PC compatibility
- Single-mode module
Product Features Comparison
| Feature | HKShanhai Group Limited SFP-GPON-ONU | TP-Link TL-SM321A | Cisco GLC-GE-100FX | D-Link DEM-310GT | HP J4858C | Netgear AGM734 |
|---|---|---|---|---|---|---|
| Data Rate (Tx/Rx) | 1.244M/2.488M | 1.25G/1.25G | 100M | 1.25G | 1.25G | 1G |
| Transmission Distance | 20km | 10km | 2km | 10km | 20km | 550m |
| Wavelength (Tx/Rx) | 1310nm/1490nm | 1310nm/1550nm | 1310nm | 850nm | 1310nm | 850nm |
| Connector Type | SC/UPC, SC/PC | LC | LC | LC | LC | LC |
| Module Type | Single-mode | Single-mode | Multi-mode | Multi-mode | Single-mode | Multi-mode |
SFP-GPON-ONU Product Application Scenarios
- Long-distance network transmission
- Fiber-to-the-Home (FTTH) deployments
- Campus-area networking
Optional Add-ons
| Accessory | Model | Description |
|---|---|---|
| Patch Cable | PC-SC20 | 20m SC to SC Single-mode Fiber Patch Cable |
| Media Converter | MC220L | TP-Link Gigabit Media Converter |
| Fiber Optic Cleaner | FOC-250 | Portable Fiber Optic Connector Cleaner |
Get More Information
Discover unbeatable prices and fast shipping for the HKShanhai Group Limited SFP-GPON-ONU. Access the detailed SFP-GPON-ONU datasheet and ensure you’re getting the best deal with our reliable delivery service. Need assistance? Our free live chat support is here to help. For more information about the product and pricing, contact us via live chat or email us at sales@router-switch.com.
HKShanhai Group Limited SFP-GPON-ONU Specification
SFP-GPON-ONU Specifications |
|
| Brand | HKShanhai Group Limited |
| Product Name | SFP-GPON-ONU |
| Type | PON Optical Transceiver |
| Form Factor | SFP |
| Transmission Speed | 1244 Mbps (Tx) / 2488 Mbps (Rx) |
| Cable Type | Single-mode |
| Wavelength | 1310nm (Tx) / 1490nm (Rx) |
| Maximum Distance | 20km |
| Connector Type | SC/UPC |
| Compatibility | SC/PC |
| Operating Temperature | 0°C to 70°C |
| Storage Temperature | -40°C to 85°C |
| Data Rate | 2.5 Gbps |
| Optical Output Power | -8 to 0 dBm |
| Receiver Sensitivity | -28 dBm |
| Power Supply Voltage | 3.3V |
| Protocol | GPON |
| Dimensions | 56.5mm x 13.7mm x 8.5mm |
| Regulatory Compliance | CE, FCC |
| Application | FTTH (Fiber to the Home) |
