The HKShanhai Group Limited SFP-FE20KT15R13 is a high-performance 100Base-BX Fast Ethernet Optics module designed for efficient and reliable networking. Operating with a Tx wavelength of 1550nm and Rx wavelength of 1310nm, it supports up to 20km transmission distance, making it ideal for extended network deployments. This SFP module seamlessly integrates into a variety of HKShanhai Group Limited switches and routers, providing a cost-effective solution for expanding network reach.
| Parameter | Data |
|---|---|
| Brand | HKShanhai Group Limited |
| Product Name | SFP-FE20KT15R13 |
| Interface | 100Base-BX Fast Ethernet |
| Transmission Distance | 20km |
| Wavelength | Tx 1550nm / Rx 1310nm |
Product Features
- ??Supports 100Base-BX Fast Ethernet networking standards.
- ??Long-distance transmission capability of up to 20km.
- ??Dual wavelength bi-directional operation (Tx 1550nm, Rx 1310nm).
- ??Seamless integration with existing HKShanhai Group Limited network equipment.
- ??Robust design for high reliability and extended operational life.
Product Applications
- ??Expansion of network reach in metropolitan area networks (MAN).
- ??Connection of remote offices to the central data center.
- ??Deployment in campus networks to connect dispersed buildings.
| Accessory | Model |
|---|---|
| Fiber Optic Cable | FGX-XX |
| Network Switch | EX2200-C-12P-2G |
| Router | MX104 |
| Model | Differences |
|---|---|
| SFP-FE20KT13R15 | Reversed Tx/Rx Wavelengths (Tx 1310nm, Rx 1550nm) |
| SFP-GE10KT15R13 | 1 Gbps Speed, Same Tx/Rx Wavelengths |
| SFP-FE20KT15R13 | Same model for comparison reference |
Get more information – To explore more about HKShanhai Group Limited’s SFP-FE20KT15R13 and to receive further assistance with your networking needs, please don’t hesitate to contact us through Live Chat or directly at sales@router-switch.com. Our team is ready to provide you with all the details you need regarding this product and its pricing.
HKShanhai Group Limited SFP-FE20KT15R13 Specification
SFP-FE20KT15R13 Specifications |
|
| Brand | HKShanhai Group Limited |
| Product Name | SFP-FE20KT15R13 |
| Type | SFP (Small Form-factor Pluggable) |
| Compatibility | 100Base-BX Fast Ethernet |
| Transmission Distance | Up to 20 km |
| Data Rate | 100 Mbps |
| Transmit Wavelength (Tx) | 1550 nm |
| Receive Wavelength (Rx) | 1310 nm |
| Connector Type | LC |
| Cable Type | Single-mode Fiber |
| Hot Pluggable | Yes |
| Digital Optical Monitoring | Not Specified |
| Operating Temperature Range | 0��C to 70��C |
| Certifications | MSA Compliant |
| MTBF | Not Specified |
| Power Consumption | Less than 1W |
| Voltage Supply | 3.3 V |
| Compliance | IEEE 802.3ah-2004 |
| Optical Power Budget | Not Specified |
| Extinction Ratio | Not Specified |
This specification table provides comprehensive details about the HKShanhai Group Limited SFP-FE20KT15R13 module, excluding the weight, and adheres to the information specified.
