Discover the HKShanhai Group Limited SFP-FE-LX-SM1550-BIDI BiDi transceiver, designed for seamless long-distance data transmission. Ideal for network engineers and IT procurement teams, this eSFP module offers impressive benefits such as 15km reach and high compatibility with single-mode fiber (SM). Perfect for scenarios requiring reliable fiber optics connectivity.
HKShanhai Group Limited SFP-FE-LX-SM1550-BIDI Product Highlights
- Tx1550nm/Rx1310nm wavelengths
- 155 Mbps speed
- -15dBm to -8dBm Tx
- -32dBm sensitivity
- LC/PC connector
Product Features Comparison
| Feature | HKShanhai Group Limited SFP-FE-LX-SM1550-BIDI | Cisco GLC-BX-D-I | Juniper EX-SFP-1GE-LX | Arista SFP-1G-LX-BIDI | Dell SFP-1G-BX-D | HP JD118B | Brocade E1MG-LX-OM |
|---|---|---|---|---|---|---|---|
| Wavelength | 1550nm/1310nm | 1490nm/1310nm | 1310nm | 1490nm/1310nm | 1490nm/1310nm | 1310nm | 1310nm |
| Data Rate | 155Mbps | 1Gbps | 1Gbps | 1Gbps | 1Gbps | 1Gbps | 1Gbps |
| Range | 15km | 10km | 10km | 10km | 10km | 10km | 10km |
| Connector | LC/PC | LC/PC | LC/PC | LC/PC | LC/PC | LC/PC | LC/PC |
| Tx Power | -15dBm to -8dBm | -9dBm to -3dBm | -9dBm to -3dBm | -9dBm to -3dBm | -9dBm to -3dBm | -9dBm to -3dBm | -9dBm to -3dBm |
| Sensitivity | -32dBm | -23dBm | -23dBm | -23dBm | -23dBm | -23dBm | -23dBm |
HKShanhai Group Limited SFP-FE-LX-SM1550-BIDI Product Application Scenarios
- Long-distance network connectivity
- Data center fiber optic links
- Telecom backbone structures
Optional Add-ons
| Model | Description |
|---|---|
| HKShanhai Group Limited SFP-GLC-LX-SM | Simplex single-mode fiber module |
| Cisco SFP-H10GB-CU1M | 1-meter copper cable for SFP |
| Juniper EX-SFP-10GE-SR | 10GbE short-reach transceiver |
Get More Information
Discover unbeatable prices and fast shipping for the HKShanhai Group Limited SFP-FE-LX-SM1550-BIDI. Access the detailed HKShanhai Group Limited SFP-FE-LX-SM1550-BIDI datasheet and ensure you’re getting the best deal with our reliable delivery service. Need assistance? Our free live chat support is here to help. For more information about the product and pricing, contact us via live chat or email us at sales@router-switch.com.
HKShanhai Group Limited SFP-FE-LX-SM1550-BIDI Specification
SFP-FE-LX-SM1550-BIDI Specifications |
|
| Transceiver Type | BiDi |
| Form Factor | eSFP |
| Tx Wavelength | 1550nm |
| Rx Wavelength | 1310nm |
| Data Rate | 155Mbps |
| Tx Power Range | -15dBm to -8dBm |
| Rx Sensitivity | -32dBm |
| Connector Type | LC/PC |
| Fiber Type | Single-mode (SM) |
| Maximum Distance | 15km |
| Operating Temperature Range | -40°C to 85°C |
| Storage Temperature | -40°C to 85°C |
| Form Factor Standard | SFP MSA |
| Compliance | RoHS, CE, FCC |
| Power Supply Voltage | 3.3V |
| Power Consumption | < 1W |
| DDM/DOM | Yes |
| Hot Swappable | Yes |
| EMI Immunity | High |
| Warranty | 1 Year |
