Introducing the Dahua SD29204UE-GN-W, a high-performance 2MP 4x Starlight IR PTZ Wi-Fi Network Camera. This sophisticated product is designed to deliver superior video surveillance with advanced imaging technology, ensuring excellent image quality even in low-light environments. Ideal for both residential and commercial applications, it is equipped with powerful features that cater to modern security needs.
Quick Spec
| Image Sensor | 1/2.8″ 2 Megapixel progressive CMOS |
| Zoom | 4x optical zoom |
| IR Distance | Up to 50 meters |
| Wi-Fi | Supported |
| Operating Conditions | -30°C ~ 60°C (-22��F ~ 140��F) |
Product Features
- 2MP resolution for clear and detailed images
- 4x optical zoom for versatile imaging
- Starlight technology for enhanced low-light sensitivity
- Up to 50m IR distance for superior night visibility
- Wi-Fi connectivity for flexible installation
Product Applications
- Residential areas needing high-definition surveillance
- Commercial properties requiring flexible camera placement
- Outdoor spaces where low-light performance is critical
Supported Options
| Protective Case | Dahua PC-SD29204UE-GN |
| Mounting Bracket | Dahua MB-SD29204UE-GN |
| Extension Cable | Dahua EC-SD29204UE-GN |
Compare to Similar Items
| Dahua SD29204UE-GN | Wired connection only, no Wi-Fi |
| Dahua SD49225T-HN | 25x optical zoom, larger IR distance |
| Dahua SD22204UE-GN-W | Similar specs but with a 2.7-11mm lens |
Get more information
For more information about the Dahua SD29204UE-GN-W, contact us through Live Chat or email at sales@router-switch.com. Check “Dahua SD29204UE-GN-W price” and “SD29204UE-GN-W datasheet”, buy “Dahua SD29204UE-GN-W network camera” with the best price and fast shipping. Free Live Chat is supported.
Dahua SD29204UE-GN-W Specification
| Model | IPC-HFW5241E-Z12E |
| Brand | Dahua |
| Camera Type | IP Camera |
| Max Resolution | 2 MP (1920 x 1080) |
| Lens Type | Motorized Varifocal Lens |
| Lens Focal Length | 5.3 mm to 64 mm |
| Night Vision | Up to 200m (656ft) |
| Day/Night | Auto (ICR) / Color / B/W |
| Protection Level | IP67 |
| Video Compression | H.265, H.264, MJPEG |
| Frame Rate | 30 fps @ 1080P |
| Operating Conditions | -40°C to +60°C (-40°F to +140°F) |
| IPC-HFW5241E-Z12E | IPC-HFW5241E-Z12E |
|
Advanced Intelligent Functions |
Face Detection |
|
Video |
|
|
Compression |
H.265/H.264/MJPEG(Sub Stream) |
|
Streaming Capability |
3 Streams |
|
Resolution |
1080P(1920Ă—1080)/720P(1280Ă—720)/D1(704Ă—576/704Ă—480)/CIF(352Ă—288/352Ă—240) |
|
Frame Rate |
Main stream: 1080P/720P/D1 (1 ~ 25/30fps) |
|
Sub stream1: D1/CIF(1 ~ 25/30fps) |
|
|
Sub stream2: 720P/D1/CIF (1 ~ 25/30fps) |
|
|
Bit Rate Control |
CBR/VBR |
|
Bit Rate |
H.265/H.264: 448K ~ 8192Kbps, MJPEG: 5120K ~ 10240Kbps |
|
Day/Night |
Auto(ICR) / Color / B/W |
|
Backlight Compensation |
BLC / HLC / WDR (120dB) |
|
White Balance |
Auto, ATW, Indoor, Outdoor, Manual |
|
Gain Control |
Auto / Manual |
|
Noise Reduction |
Ultra DNR (2D/3D) |
|
Motion Detection |
Support |
|
Region of Interest |
support |
|
Electronic Image Stabilization (EIS) |
N/A |
|
Defog |
Support |
|
Digital Zoom |
16x |
|
Flip |
180° |
|
Privacy Masking |
Up to 24 areas |
|
Audio |
|
|
Compression |
G.711a/G.711mu/PCM/G.726/AAC/G722.1/G.729/MPEG2-Layer2 |
|
Network |
|
|
Ethernet |
RJ-45 (10XBase-T/100Base-TX) |
|
Wifi |
Support |
|
Protocol |
IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS,PPPOE,DDNS,FTP, IP Filter,QoS,Bonjour,802.1x |
|
Interoperability |
ONVIF Profile S&G, API |
|
Streaming Method |
Unicast / Multicast |
|
Max. User Access |
20 users |
|
Edge Storage |
NAS (Network Attached Storage),Local PC for instant recording, Micro SD card 128GB |
|
Web Viewer |
IE, Chrome, Firefox, Safari |
|
Management Software |
Smart PSS, DSS, DMSS |
|
Smart Phone |
IOS, Android |
|
Certifications |
|
|
Certifications |
CE: EN55032/EN55024/EN50130-4 FCC: Part15 subpartB,ANSI C63.4- 2014 UL: UL60950-1+CAN/CSA C22.2,No.60950-1 |
|
Interface |
|
|
Video Interface |
N/A |
|
RS485 |
N/A |
|
Audio I/O |
Built-in Mic |
|
Alarm I/O |
N/A |
|
Electrical |
|
|
Power Supply |
DC 12V/1.5A |
|
Power Consumption |
10W,13W (IR on) |
|
Environmental |
|
|
Operating Conditions |
-30°C ~ 60°C (-22°F ~ +140°F) / Less than 90% RH |
|
Ingress Protection |
N/A |
|
Vandal Resistance |
N/A |
|
Construction |
|
|
Casing |
Metal |
|
Dimensions |
Φ132.7 (mm) x 117.9 (mm) |
|
Net Weight |
0.95kg(2.09lb) |
|
Gross Weight |
1kg(2.20lb) |
