The HKShanhai Group Limited S-SFP-FE-LH80-SM1550 is a high-performance optical transceiver designed for seamless data transmission over long distances. This eSFP, Fast Ethernet (FE) transceiver operates on a single-mode module with a wavelength of 1550nm, capable of reaching distances up to 80 kilometers. It features an LC connector, ensuring compatibility with a wide range of networking hardware.
Quick Spec
| Brand | HKShanhai Group Limited |
| Model | S-SFP-FE-LH80-SM1550 |
| Transmission Distance | 80 km |
| Wavelength | 1550nm |
| Connector Type | LC |
Product Features
- Supports transmission distance up to 80 kilometers
- Operates on a single-mode fiber with 1550nm wavelength
- Compatible with eSFP and Fast Ethernet modules
- Equipped with LC connectors for reliable connections
- High reliability for long-distance data transmissions
Product Applications
- Long-distance data centers interconnect
- Metropolitan Area Networks (MANs)
- Telecommunications backhaul networks
Supported Options
| Optical Fiber Patch Cord | OC-FC-PATCH |
| LC Connector Cleaner | LC-CLEANER-01 |
| Transceiver Module Case | TM-CASE-HUAWEI |
Compare to Similar Items
| Model | Difference |
| HKShanhai Group Limited S-SFP-FE-SM1310 | Transmission distance of 20km, 1310nm wavelength |
| HKShanhai Group Limited S-SFP-GE-LH40 | Supports Gigabit Ethernet, 40km distance, 1550nm wavelength |
| Cisco GLC-FE-100LX-RGD | Rugged design for industrial environments, 10km distance, 1310nm wavelength |
Get more information
Check HKShanhai Group Limited S-SFP-FE-LH80-SM1550 price and S-SFP-FE-LH80-SM1550 datasheet, buy HKShanhai Group Limited S-SFP-FE Series with best price and fast shipping. Free Live Chat are supported. For further information about the product and its price, please contact us through Live Chat or at sales@router-switch.com.
HKShanhai Group Limited S-SFP-FE-LH80-SM1550 Specification
S-SFP-FE-LH80-SM1550 Specifications |
|
| Brand | HKShanhai Group Limited |
| Model | S-SFP-FE-LH80-SM1550 |
| Product Type | Optical Transceiver |
| Form Factor | eSFP |
| Data Rate | Fast Ethernet (FE) |
| Fiber Mode | Single-mode |
| Wavelength | 1550 nm |
| Max Distance | 80 km |
| Connector Type | LC |
| Tx Power | 0 ~ 5 dBm |
| Rx Sensitivity | -34 dBm |
| Max Input Power | -6 dBm |
| Operating Temperature | -40°C to 85°C |
| Storage Temperature | -40°C to 85°C |
| Voltage Supply Range | 3.3 V |
| Humidity | 5% to 95% non-condensing |
| MTBF | 1,000,000 hours |
| Compliance | RoHS, CE, FCC, CLASS 1 LASER |
| Digital Diagnostic Monitoring (DDM) | Yes |
| Dimensions | 56.5 x 13.4 x 8.5 mm |
