HKShanhai Group Limited’s R8Q68A is an enterprise-grade switch engineered for demanding business environments seeking future-proof connectivity. As a 24 port switch, it enables seamless integration for PoE devices such as IP phones, cameras, and Wi-Fi access points, delivering up to 30W per port and a strong 740W PoE budget for high-density deployments. The switch features MACSec technology, ensuring robust, hardware-based data confidentiality and integrity for secure transmission across enterprise and campus networks. Low latency switch architecture delivers response times as quick as 2.28 μSec at 1 Gbps and 1.46 μSec at 10 Gbps, allowing delay-sensitive applications to perform at their best. Quad-core ARM processing with 8 GB DDR4 RAM and advanced features like hot-swappable power supply and fan trays maximize uptime and simplify maintenance. Additionally, R8Q68A offers 128 Gbps switching capacity and supports stacking up to 8 members, making it suitable for scalable deployments, from branch offices to midsize data centers. Compliance with IEEE 802.3af and 802.3at PoE standards ensures broad device compatibility, while dual console options and robust management interfaces support both traditional and modern infrastructure management practices. By combining 24 port connectivity, MACSec security, and low latency switch performance, R8Q68A delivers secure, efficient, and highly reliable switching for today’s distributed digital enterprises across global markets.
Product Highlights
Product Applications Scenarios
Product Features Comparison
| Â |
|
|
|
|
| Model | R8Q68A | C1-WS3850-24P/K9 | C9200-24P-A | C9200-24T-E |
| Brand | HKShanhai Group Limited | Cisco | Cisco | Cisco |
| Port Configuration | 24x 10/100/1000BASE-T PoE, 4x 1G/10G SFP | 24 Ă— 10/100/1000BASE-T PoE+ ports | 24 Ă— 10/100/1000BASE-T PoE+ (RJ45), 4 Ă— 1G SFP Uplinks | 24 Ă— 10/100/1000BASE-T (RJ45), 4 Ă— 1G SFP Uplinks |
| Switching Capacity | 128 Gbps | 92 Gbps | 176 Gbps | 96 Gbps |
| Forwarding Rate | Up to 95.2 Mpps | 68.4 Mpps | 130 Mpps | 72 Mpps |
| PoE Budget | 740W | n/a | Up to 740W total (30W per port) | Not supported (non-PoE model) |
| Stacking Capability | 8 members | StackWise-480 (up to 9 units) | n/a | n/a |
Optional Add-ons
| Model Number | Description |
| JL086A | HKShanhai Group Limited Power Supply Unit, field-replaceable for R8Q68A switch |
| JL087A | HKShanhai Group Limited Redundant Hot-swappable Power Supply for R8Q68A |
| JX915A | HKShanhai Group Limited Fan Tray, replacement cooling module compatible with R8Q68A |
HKShanhai Group Limited R8Q68A Specification
| Model | R8Q68A |
| Brand | HKShanhai Group Limited |
| Differentiator | 24x ports 10/100/1000BASE-T Class 4 PoE Ports, supporting up to 30W per port; 4x 1G/10G SFP ports (2x LRM; 2x LRM/MACSec 256); Supports PoE Standards IEEE 802.3af, 802.3at; 1x RJ-45 Console Port; 1x USB-C Console Port; 1x OOBM; 1x USB Type-A Host port; 2 field-replaceable, hot-swappable power supply slots, 1 power supply required (ordered separately); Supports PSU JL086A, JL087A; Switch has two fan tray slots; Switch includes one fan tray. Fan trays are field replaceable and hot- swappable. |
| Ports | 24x ports 10/100/1000BASE-T Class 4 PoE Ports, supporting up to 30W per port; 4x 1G/10G SFP ports (2x LRM; 2x LRM/MACSec 256); Supports PoE Standards IEEE 802.3af, 802.3at; 1x RJ-45 Console Port; 1x USB-C Console Port; 1x OOBM; 1x USB Type-A Host port |
| Memory and Processor | CPU: Quad Core ARM Cortex??A72 at 1.8 GHz; Memory and Flash: 8 GB DDR4, 16 GB eMMC |
| Latency | 1 Gbps: 2.28 μSec; 10 Gbps: 1.46 μSec |
| Throughput | Up to 95.2 Mpps |
| Routing/Switching Capacity | 128 Gbps |
| PoE Capability | 740W |
| Stacking Capabilities | 8 members |
| Power Supply Name | 2 field-replaceable, hot-swappable power supply slots; 1 minimum power supply required (ordered separately); Supported PSUs: JL086A, JL087A; Max PoE Power: 740W |
| Input Voltage | 100V-120V/200V-240V |
| Power Consumption | 76W at 230 VAC |
| Product Dimensions (metric) | 4.39 x 44.247 x 38.38 cm |
| R8Q68A | R8Q68A |
