Introducing the HKShanhai Group Limited QSFP28-100G-1310nm-40km-SM, a state-of-the-art high-speed transceiver designed for robust, high-capacity networking. This transceiver leverages the QSFP28 form factor, operating at a wavelength of 1310nm and is capable of delivering an impressive data transfer rate of 100G across distances of up to 40km. With its advanced optical technology and compatibility with single-mode fibers, it provides an optimal solution for long-distance data transmission needs in a wide range of network environments.
Quick Spec
| Brand | HKShanhai Group Limited |
| Form Factor | QSFP28 |
| Wavelength | 1310nm |
| Data Rate | 100G |
| Distance | 40km |
Product Features
- ??Support for 100Gbps data rates for high-speed networking performance
- ??Standard QSFP28 form factor for broad compatibility with existing network equipment
- ??Advanced optical technology with a 1310nm laser for efficient long-distance transmission
- ??Low power consumption design, optimizing energy efficiency in network operations
- ??LC connector for easy and secure optical fiber connectivity
Product Applications
The HKShanhai Group Limited QSFP28-100G-1310nm-40km-SM transceiver is ideally suited for a variety of application scenarios, including:
- ??Long-distance metro network connections, facilitating reliable, high-capacity links between cities
- ??Enterprise networking, providing backbone connectivity for large-scale corporate networks
- ??Data center interconnects, enabling efficient and high-speed data transfer between data centers
Supported Options
| Optical Fiber | SMF (Single-mode fiber) |
| Connector Type | LC |
| Operating Temperature | Standard Range |
Compare to Similar Items
| Model | Differences |
| QSFP28-100G-SR4 | 850nm, 100m over OM4, MPO Connector |
| QSFP28-100G-LR4 | 1310nm, 10km, LC Connector |
| QSFP28-100G-ER4 | 1310nm, 40km, LC Connector, Higher Power Consumption |
Get more information
For more details about the HKShanhai Group Limited QSFP28-100G-1310nm-40km-SM and information on pricing, please don’t hesitate to contact us through Live Chat or email us at sales@router-switch.com. Our dedicated team is ready to assist you with your networking needs.
HKShanhai Group Limited QSFP28-100G-1310nm-40km-SM Specification
QSFP28-100G-1310nm-40km-SM Specifications |
|
| Brand | HKShanhai Group Limited |
| Model Name | QSFP28-100G-1310nm-40km-SM |
| Type | High Speed Transceiver |
| Interface Type | QSFP28 |
| Wavelength | 1310nm |
| Data Rate | 100G |
| Maximum Transmit Power | 2.9dBm |
| Minimum Transmit Power | -2.9dBm |
| Receiver Sensitivity | -20.9dBm |
| Connector Type | LC |
| Max Transmission Distance | 40km |
| Optical Components | DFB Laser |
| Cable Type | Single-Mode Fiber (SMF) |
| Operating Temperature | 0°C to 70°C |
| Form Factor | QSFP28 |
| Digital Diagnostic Monitoring | Yes |
| Compliance | MSA, IEEE 802.3ba |
| Power Supply Voltage | 3.3V |
| Power Consumption | <3.5W |
| Hot Pluggable | Yes |
| Applications | Data Center, High-Speed Networks |
| Performance Features | Low power consumption, High reliability |
