The Dahua PFS3125-24ET-190 is a high-performance 24-Port FE PoE+ switch equipped with 1-Port Gigabit Combo PoE. This switch is designed to offer superior power and data connectivity for network devices, making it ideal for both small and medium-sized businesses. Experience enhanced network performance and reliability with Dahua°s cutting-edge PoE switch technology.
Quick Spec
| Brand | Dahua |
| Model | PFS3125-24ET-190 |
| Ports | 24 FE PoE+, 1 Gigabit Combo |
| PoE Power Budget | 190W |
| Dimensions | 440 mm ° 300 mm ° 44 mm |
| Switching Capacity | 8.8 Gbps |
Product Features
- 24 FE PoE+ ports with a power budget of 190W
- 1 Gigabit Combo (RJ45/SFP) port for flexible connectivity options
- Supports PoE over long distance up to 250 meters
- Advanced security features including IP-MAC-Port-VID binding
- High-performance switching capacity of 8.8 Gbps
Product Applications
- Small to medium-sized business networks requiring robust PoE capabilities
- IP surveillance systems with multiple IP cameras and devices
- Remote office locations needing reliable PoE and data connectivity
Supported Options
| Accessory | Model |
| SFP Module | DEM-311GT |
| PoE Injector | POE-48-24W-G |
| Power Supply | PWR-190W-POE |
Compare to Similar Items
| Model | Differences |
| Dahua PFS3118-16ET-135 | 16 FE PoE+ ports, 1 Gigabit Combo, 135W PoE budget |
| Dahua PFS3424-24GT-360 | 24 Gigabit PoE+ ports, 360W PoE budget |
| Dahua PFS4218-16GT-240 | 16 Gigabit PoE+ ports, 240W PoE budget |
Get more information
Check Dahua PFS3125-24ET-190 price and PFS3125-24ET-190 datasheet, buy Dahua PFS3125-24ET-190 Switch with best price and fast shipping. Free Live Chat is supported. For further information, please contact us through Live Chat or sales@router-switch.com.
Dahua PFS3125-24ET-190 Specification
PFS3125-24ET-190 Specifications |
|
| Brand | Dahua |
| Model | PFS3125-24ET-190 |
| Port Configuration | 24 x 10/100 Mbps PoE/PoE+ Ports, 1 x Gigabit Combo (RJ45/SFP) Port |
| Supported Standards | IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE802.3x, IEEE802.3af, IEEE802.3at |
| Switching Capacity | 8.8 Gbps |
| Packet Forwarding Rate | 6.55 Mpps |
| MAC Address Table | 8K |
| Jumbo Frame | Up to 9 KB |
| Power Supply | AC 100-240V, 50/60 Hz |
| Power Consumption | Max 190W |
| PoE Budget | 190W |
| PoE Power Output | 30W per port (Max) |
| Operating Temperature | -10° to 55°C (14° to 131°F) |
| Storage Temperature | -20° to 70°C (-4° to 158°F) |
| Operating Humidity | 10% to 90% RH, Non-condensing |
| LED Indicators | Power, Link/Activity, PoE |
| Dimensions (W x D x H) | 440 mm x 300 mm x 44 mm (17.3″ x 11.8″ x 1.7″) |
| Cooling | Fanless |
| Warranty | 3 Years |
| Mounting | Rack-mountable |
| Certification | FCC, CE, RoHS |
| Management | Web-based GUI, SNMP |
