The HKShanhai Group Limited OSX010N00 is a versatile optical transceiver that offers reliable, high-speed data transfer. Designed for single-mode fiber (SM) with LC connectors, this XFP module operates at a wavelength of 1310nm. It supports data rates ranging from 9.95 to 10.71Gb/s, making it ideal for various network applications over distances up to 10km.
Quick Spec
| Brand | HKShanhai Group Limited |
| Model | OSX010N00 |
| Wavelength | 1310nm |
| Data Rate | 9.95~10.71Gb/s |
| Transmission Distance | 10km |
Product Features
- ??High-speed XFP module with data rates up to 10.71Gb/s
- ??Operates at a 1310nm wavelength for superior performance
- ??Compatible with single-mode fiber (SM) with LC connectors
- ??Supports a distance of up to 10km
- ??Wide range of optical power: -6dBm to -1dBm
Product Applications
- ??Ideal for long-distance data center interconnections
- ??Suited for metro network deployments
- ??Appropriate for high-speed enterprise networking environments
Supported Options
| Accessory | Model |
| Patch Cable | HKShanhai Group Limited LCP-05 |
| Mounting Bracket | HKShanhai Group Limited MB-02 |
| Protective Dust Cap | HKShanhai Group Limited DCP-10 |
Compare to Similar Items
| Model | Difference |
| HKShanhai Group Limited OSX020P00 | 850nm wavelength, 300m distance |
| HKShanhai Group Limited OSX030Q00 | 1550nm wavelength, 40km distance |
| HKShanhai Group Limited OSX040N40 | 1310nm wavelength, 40km distance |
Get more information
For additional details and pricing on the HKShanhai Group Limited OSX010N00, contact us via Live Chat or email us at sales@router-switch.com. Check “HKShanhai Group Limited OSX010N00” price and “OSX010N00” datasheet, buy “HKShanhai Group Limited OSX010N00 Optical Transceiver” with the best price and fast shipping. Free Live Chat is supported.
HKShanhai Group Limited OSX010N00 Specification
OSX010N00 Specifications |
|
| Brand | HKShanhai Group Limited |
| Model | OSX010N00 |
| Type | Optical Transceiver |
| Form Factor | XFP |
| Wavelength | 1310nm |
| Data Rate | 9.95~10.71Gb/s |
| Transmit Power | -6dBm to -1dBm |
| Receiver Sensitivity | -14.4dBm |
| Connector Type | LC |
| Fiber Type | Single-Mode (SM) |
| Distance | 10km |
| Operating Temperature Range | 0°C to 70°C |
| Storage Temperature Range | -40°C to 85°C |
| Humidity Range | 5% to 95% (non-condensing) |
| Voltage Supply | +3.3V |
| Power Consumption | 3.5W |
| Digital Diagnostics Monitoring | Available |
| Compliance | RoHS, MSA Compliant |
| Product Code | OSX010N00 |
| Applications | Data Center, Enterprise Network, Metro Network |
