The Alcatel-Lucent OS6860E-24D is an enterprise-class switch engineered for rack mount environments, designed to address advanced requirements in enterprise networks and data center aggregation. This Alcatel-Lucent switch stands out for its rich L3 managed feature set and seamless scalability, making it ideal for organizations seeking dependable and efficient networking solutions. As an integral part of an enterprise network, the OS6860E-24D provides robust data traffic management, prioritizing security, application visibility, and operational efficiency. Its data center aggregation capabilities support high-density connectivity while maintaining simplicity in rack mount deployment. With 24 Gigabit Ethernet ports, flexible stacking, and comprehensive protocol support, the OS6860E-24D enhances network reliability and streamlines highly available business operations. It features front-to-back airflow for optimal cooling in dense rack configurations and supports advanced network functions including VLAN, IPv6, load balancing, and port mirroring. This device is engineered to facilitate smooth operations across diverse deployment scenarios, ensuring high throughput and secure management access for network administrators, integrators, and end users alike. The OS6860E-24D delivers a powerful combination of layer 3 switching, security features, and management tools, making it the ideal choice for organizations requiring an Alcatel-Lucent switch with proven performance in enterprise network and data center aggregation environments, all in a rack mount-ready form factor.
Product Highlights
Product Applications Scenarios
Product Features Comparison
|
|
|
|
|
|
| Model | OS6860E-24D | C1-WS3850-24U/K9 | C1000-16P-E-2G-L | C9300L-24P-4G-A |
| Brand | Alcatel-Lucent | Cisco | Cisco | Cisco |
| Port Configuration | 24 x 10/100/1000Base-T RJ-45, 4 x 10 Gigabit SFP+, 2 x QSFP+ stacking, 1 x USB management, 1 x console management, 1 x RS-232 management | 24 × 10/100/1000BASE-T ports | 16 × 10/100/1000BASE-T PoE+ (RJ45, IEEE 802.3af/at) 2 × SFP Uplinks (1000BASE-X) |
n/a |
| Switching Capacity | 224 Gbps | 92 Gbps | 36 Gbps | 56 Gbps – 176 Gbps |
| Forwarding Rate | 154.9 Mpps | 68.4 Mpps | 26.78 Mpps (64-byte L3 packets) | 41.66 Mpps – 130.95 Mpps |
| PoE Budget | n/a | n/a | 195W (total) | n/a |
| Stacking Capability | Max 8 units in a stack, max supported qty: 2 | StackWise-480 (up to 9 units) | n/a | StackWise-320 |
Optional Add-ons
| Model Number | Description |
| OS6860E-PWR | Alcatel-Lucent hot-plug redundant power supply module for OS6860E Switch Series |
| SFP-10G-LR | Alcatel-Lucent 10G SFP+ LR Optical Module, suitable for long-range data center links |
| OS6860-LIC | Software feature license for advanced layer 3 capabilities on Alcatel-Lucent OS6860E switches |
Alcatel-Lucent OS6860E-24D Specification
| Model | OS6860E-24D |
| Brand | Alcatel-Lucent |
| Device Type | Switch – 24 ports – L3 – Managed – Stackable |
| Enclosure Type | Front to back airflow, rack-mountable 1U |
| Ports | 24 x 10/100/1000Base-T RJ-45, 4 x 10 Gigabit SFP+, 2 x QSFP+ stacking, 1 x USB management, 1 x console management, 1 x RS-232 management |
| Subtype | Gigabit Ethernet |
| Stacking Capacity | Max 8 units in a stack, max supported qty: 2 |
| Capacity | IPv4 routes: 64,000, VLANs: 4,000 |
| MAC Address Table Size | 48K entries |
| Jumbo Frame Support | 9216 bytes |
| Performance | Switching capacity: 224 Gbps, Throughput (64-byte packet size): 154.9 Mpps |
| RAM | 2 GB |
| Flash Memory | 2 GB |
| Authentication Methods | SSH, RADIUS, TACACS+, SSH2, LDAP, EAP |
| Encryption Algorithms | MD5, PKI |
| Features | Flow control, BOOTP support, ARP support, load balancing, VLAN support, IGMP snooping, Syslog support, port mirroring, DiffServ support, IPv6 support, deep inspection, Dying Gasp support, STP and Rapid STP |
| Routing Protocols | IS-IS, RIP-1, RIP-2, IGMPv2, IGMP, VRRP, static IP routing, IGMPv3, GRE, PIM-SSM, MLDv2, MLD, VRRPv2, BFD, CIDR |
| Remote Management Protocols | SNMP v1/v2/v2c/v3, RMON, Telnet, HTTP, HTTPS, TFTP, CLI |
| Status Indicators | Power, status, redundant power supply (RPS), link/activity |
| Power Device | Internal power supply, hot-plug, optional redundancy (1+1 with optional power supply) |
| Power Consumption | 48 W operational |
| Voltage Required | DC -36 to -72 V |
| MTBF | 353,806 hours |
| Installed Size | 1 |
| Cables Included | 1 x micro-USB to USB adapter |
| Rack Mounting Kit | Included |
| Humidity Range Operating | 5% – 95% (non-condensing) |
| Humidity Range Storage | 5% – 95% (non-condensing) |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 45 °C |
| Min Storage Temperature | -40 °C |
| Max Storage Temperature | 85 °C |
| Height | 4.4 cm |
| Width | 44 cm |
| Depth | 35 cm |
| Version | Original |
| Compliant Standards | BSMI, EN 61000-3-2, EN55022, GS, EN 61000-3-3, EN55024, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, CCC, EN 61000-4-5, EN 61000-4-11, RoHS, EN 61000-4-8, UL 60950-1, IEC 60950-1, KCC, WEEE, FCC CFR47, ANATEL, UL-AR, EN 60825-1, AS/NZS 3548 Cla |
| OS6860E-24D | OS6860E-24D |
