The Alcatel-Lucent OS6860E-24 is an advanced enterprise-grade switch engineered for the modern needs of enterprise networks across diverse regions and industries. As a robust 24-port, L3 managed and stackable solution, it is ideal for organizations seeking reliable Ethernet connectivity with flexible deployment options. Featuring comprehensive support for SFP+ ports, the OS6860E-24 offers seamless high-speed uplinks that are essential for data-intensive tasks and scalable architectures. Advanced routing protocols equip the switch to anchor the core of enterprise connectivity, enhancing network agility, segmentation, and policy control. The switch delivers optimized throughput and robust switching capacity, supporting high-density user environments and business-critical workloads. Enterprise customers and integrators benefit from versatile management interfaces—USB, RS-232 serial, and console—catering to both local and remote administration requirements. Its support for cutting-edge authentication methods (SSH, RADIUS, TACACS+, and more), together with strong encryption protocols, provides a secure foundation for business communication and sensitive data. Compliance with global standards ensures compatibility and dependable operation in multi-vendor networks. Enhanced VLAN and jumbo frame capacities, along with front-to-back airflow and 1U rack-mounting versatility, mean the OS6860E-24 adapts well to different data center and telecommunications environments. Whether for distributed branches or central hubs, this Alcatel-Lucent switch empowers organizations to future-proof their network investments, simplify network management, and scale operations confidently. By leveraging top-tier enterprise features, robust performance, and advanced security, the OS6860E-24 is a reliable cornerstone for business transformation and digital growth.
Product Highlights
Product Applications Scenarios
Product Features Comparison
|
|
|
|
|
|
| Model | OS6860E-24 | C1-WS3650-24XPD/K9 | C1-WS3650-48FS/K9 | C9300-24UX-A |
| Brand | Alcatel-Lucent | Cisco | Cisco | Cisco |
| Port Configuration | 24 x 10/100/1000Base-T RJ-45, 4 x SFP+, 2 x QSFP+, USB/console/RS-232 Mgmt | 24 × 10/100/1000BASE-T PoE+ ports, 4 × 1G SFP uplinks | 48 × 10/100/1000BASE-T Ports, 4 × SFP (1G) Uplinks | 24 Multigigabit Cisco UPOE (100 Mbps or 1, 2.5, 5, or 10 Gbps) |
| Switching Capacity | 224 Gbps | 92 Gbps | 176 Gbps | 640 Gbps on 24-port Multigigabit Ethernet model |
| Forwarding Rate | 154.9 Mpps | 41.66 Mpps | 77.37 Mpps | 154.76 Mpps |
| PoE Budget | n/a | Up to 250W (with PWR-C2-250WAC) | n/a | 490W |
| Stacking Capability | 8 | up to 9 units (StackWise-160) | up to 9 (StackWise-160) | Yes |
Optional Add-ons
| Model Number | Description |
| OS6860E-BP | Backup power supply unit ??Alcatel-Lucent OS6860E series, ensures redundancy and high availability. |
| SFP-10G-LR | Alcatel-Lucent 10GbE SFP+ LR transceiver module, suitable for long-range fiber uplinks. |
| OS6860E-MNT | 1U rack-mounting kit for Alcatel-Lucent OS6860E switches, enables secure installation in standard racks. |
Alcatel-Lucent OS6860E-24 Specification
| Model | OS6860E-24 |
| Brand | Alcatel-Lucent |
| Device Type | Switch – 24 ports – L3 – Managed – Stackable |
| Subtype | Gigabit Ethernet |
| Ports | 24 x 10/100/1000Base-T RJ-45, 4 x 10 Gigabit Ethernet / 1 Gigabit Ethernet SFP+, 2 x QSFP+ stack, 1 x USB management, 1 x console management, 1 x RS-232 serial management |
| Max Units in a Stack | 8 |
| Performance | Switching capacity: 224 Gbps, Throughput (64-byte packet): 154.9 Mpps |
| MAC Address Table Size | 48K entries |
| Capacity | IPv4 routes: 64,000; Virtual interfaces (VLANs): 4,000 |
| Jumbo Frame Support | 9216 bytes |
| RAM | 2 GB |
| Flash Memory | 2 GB |
| Authentication Method | Secure Shell (SSH), Secure Shell v.2 (SSH2), RADIUS, TACACS+, LDAP, Extensible Authentication Protocol (EAP) |
| Encryption Algorithm | MD5, PKI |
| Remote Management Protocol | SNMP 1, SNMP 2, SNMP 3, SNMP 2c, RMON, Telnet, HTTP, HTTPS, TFTP, CLI |
| Routing Protocols | IS-IS, RIP-1, RIP-2, IGMPv2, IGMP, VRRP, static IP routing, IGMPv3, GRE, PIM-SSM, MLDv2, MLD, VRRPv2, Bidirectional Forwarding Detection (BFD), CIDR |
| Features | Flow control, BOOTP support, ARP support, load balancing, VLAN support, IGMP snooping, Syslog support, port mirroring, DiffServ support, IPv6 support, deep inspection, Dying Gasp support, STP support, Rapid STP support |
| Status Indicators | Power, status, RPS (Redundant Power Supply), link/activity |
| Power Device | Internal power supply – hot-plug |
| Power Consumption Operational | 48 W |
| Power Redundancy | Optional |
| Power Redundancy Scheme | 1+1 (with optional power supply) |
| Voltage Required | DC -36 to -72 V |
| Enclosure Type | Front to back airflow, rack-mountable 1U |
| Dimensions (W x D x H) | 44 cm x 35 cm x 4.4 cm |
| MTBF | 353,806 hours |
| Operating Temperature Range | 0°C to 45°C |
| Storage Temperature Range | -40°C to 85°C |
| Operating Humidity | 5% to 95% (non-condensing) |
| Storage Humidity | 5% to 95% (non-condensing) |
| Compliant Standards | BSMI, EN 61000-3-2, EN55022, GS, EN 61000-3-3, EN55024, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, CCC, EN 61000-4-5, EN 61000-4-11, RoHS, EN 61000-4-8, UL 60950-1, IEC 60950-1, KCC, WEEE, FCC CFR47, ANATEL, UL-AR, EN 60825-1, AS/NZS 3548 Cla |
| Version | Original |
| Included Accessories | 1 x micro-USB to USB adapter, rack mounting kit |
| Installed Size | 1 |
| Max Supported Qty | 2 |
| OS6860E-24 | OS6860E-24 |
