The Alcatel-Lucent OS6450-U24X is an enterprise-class switch meticulously crafted for high-performance enterprise networking. This model is purpose-built for modern Gigabit Ethernet chassis deployments, delivering robust connectivity and security for demanding metro applications. Designed to support the evolving needs of medium to large-scale networks, the OS6450-U24X features high-density SFP ports to ensure flexible fiber and copper uplink options, catering to data aggregation and high-bandwidth distribution scenarios. Its managed, stackable L3 architecture provides seamless integration and scalable growth, making it a compelling option for organizations targeting reliable, low-latency data transport across geographically dispersed environments. The switch is engineered to support up to 8 units in a stack, with advanced protocol compatibility, robust VLAN and ACL capacities, and extensive security features such as MD5 and PKI encryption. Whether supporting traffic in a metro environment, bridging distributed campus segments, or forming the core of a critical enterprise infrastructure, the OS6450-U24X stands as a versatile solution that leverages SFP ports to handle dynamic connectivity for today’s fiber-centric networks. With careful power management, an internal supply, and optional redundancy, this switch provides both uninterrupted service and operational flexibility required for mission-critical enterprise networking.
Product Highlights
Product Applications Scenarios
Product Features Comparison
| Â |
|
|
|
|
| Model | OS6450-U24X | OS6450-24XM | OS6450-P24 | C9200L-24P-4G-A |
| Brand | Alcatel-Lucent | Alcatel-Lucent | Alcatel-Lucent | Cisco |
| Port Configuration | 22 x Gigabit SFP, 2 x 10 Gigabit Ethernet / 1 Gigabit Ethernet SFP+, 2 x combo Gigabit SFP | 24 x 10/100/1000Base-T + 2 x SFP+ | 24 x 10/100/1000 (PoE+) + 2 x SFP+ | 24 Ă— 10/100/1000BASE-T (RJ45) with PoE+ support; 4 Ă— 1G SFP uplinks |
| Switching Capacity | n/a | n/a | n/a | 96 Gbps |
| Forwarding Rate | n/a | n/a | n/a | 72 Mpps |
| PoE Budget | n/a | n/a | PoE+ | 370W |
| Stacking Capability | Up to 8 units | 8 | 8 | n/a |
Optional Add-ons
| Model Number | Description |
| OS6450-FAN | Alcatel-Lucent OS6450 Series Field Replaceable Fan Module, ensures adequate system cooling for enterprise deployments. |
| OS6450-BPS | Alcatel-Lucent Backup Power Supply Unit for OS6450 Series, provides power redundancy and operational assurance. |
| SFP-GIG-LX | Alcatel-Lucent Gigabit Ethernet SFP LX Transceiver, enables long-distance fiber connectivity for OS6450 Series switches. |
Alcatel-Lucent OS6450-U24X Specification
| Model | OS6450-U24X |
| Brand | Alcatel-Lucent |
| Device Type | Switch – 24 ports – L3 – Managed – Stackable |
| Subtype | Gigabit Ethernet |
| Ports | 22 x Gigabit SFP, 2 x 10 Gigabit Ethernet / 1 Gigabit Ethernet SFP+, 2 x combo Gigabit SFP |
| Expansion Slots | 1 (total) / 1 (free) x Expansion Slot |
| Interfaces | 24 x SFP, 2 x RJ-45, 2 x SFP+, 1 x USB 2.0 Type A, 1 x console RJ-45 management |
| MAC Address Table Size | 16,000 entries |
| Performance | Port-to-port latency: 4 μs |
| Capacity | VLANs: 4000; ACL entries: 2048; RIP routes: 256; Static routes: 256 |
| Stacking | Up to 8 units |
| MTBF | 364,214 hours |
| Enclosure Type | 1U |
| Dimensions (W x D x H) | 44 cm x 31.24 cm x 4.4 cm |
| Operating Temperature | 0 °C to 45 °C |
| Storage Temperature | -40 °C to 75 °C |
| Operating Humidity | 5% ??95% |
| Storage Humidity | 5% ??95% |
| Power Device | Internal power supply |
| Power Consumption | 56.26 W |
| Power Redundancy | Optional |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Encryption Algorithm | MD5, PKI |
| Status Indicators | Port transmission speed, power, system, link/activity |
| Remote Management Protocols | SNMP 1, SNMP 2, SNMP 2c, SNMP 3, RMON, Telnet, TFTP, SSH-2, CLI |
| Routing Protocols | RIP-1, RIP-2, RIPng, IGMPv2, IGMP, IGMPv3, MLD, static IPv4 routing, static IPv6 routing, CIDR |
| Features | Flow control, auto-sensing per device, auto-negotiation, BOOTP support, ARP support, VLAN support, auto-uplink (auto MDI/MDI-X), Syslog support, DoS attack prevention, port mirroring, Weighted Round Robin (WRR) queuing, Broadcast Storm Control, IPv6 support |
| Version | Original |
| Compliant Standards | EN 61000-3-2, EN55022, NOM, VCCI Class A ITE, EN 61000-3-3, EN55024, UL 60950, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, EMC, EN 61000-4-5, EN 61000-4-11, EN 61000-4-8, IEC 60950-1, EN 60950-1, UL-AR, EN 60825-1, HMAC, AS/NZS 3548 Class A, C |
| OS6450-U24X | OS6450-U24X |
