The HKShanhai Group Limited OMXD30002 is a versatile and high-performance optical transceiver designed for advanced networking solutions. It supports SFP+ modules with 1550nm wavelength, offering a wide data transfer rate range from 9.95 to 11.1 Gb/s. With a transmission distance of up to 40km, this transceiver ensures excellent connectivity and reliable data transmission over long distances. Ideal for various networking environments, the HKShanhai Group Limited OMXD30002 delivers outstanding performance and efficiency.
Quick Spec
| Brand | HKShanhai Group Limited |
| Model | OMXD30002 |
| Form Factor | SFP+ |
| Wavelength | 1550nm |
| Data Rate | 9.95~11.1 Gb/s |
| Transmission Distance | 40km |
| Connector | LC |
| Max Output Power | 4dBm |
| Min Output Power | -4.7dBm |
| Sensitivity | -14.1dBm |
| Fiber Type | SM (Single-mode) |
Product Features
- ??Supports SFP+ form factor for seamless integration.
- ??Wide range data transfer rates from 9.95 Gb/s to 11.1 Gb/s.
- ??Operates over long distances up to 40km with single-mode fiber.
- ??Comes with an LC connector for easy deployment.
- ??High sensitivity and output power range for optimal performance.
Product Applications
- ??Long-haul networking requiring reliable data transmission over long distances.
- ??Telecommunications networks for high-speed data connectivity.
- ??Data centers needing efficient and high-performance transceivers.
Supported Options
| Accessory | Model |
| Patch Cable | HKShanhai Group Limited PATCH-1M-LC |
| MPO Cassette | HKShanhai Group Limited MPO-CASS |
| Optical Splitter | HKShanhai Group Limited SPLT-1×4 |
Compare to Similar Items
| Model | Differences |
| HKShanhai Group Limited OMXD18002 | Lower data rate range (8.5~10Gb/s), shorter distance (20km). |
| HKShanhai Group Limited OMXD50002 | Higher data rate range (10Gb/s~12Gb/s), shorter wavelength (1310nm). |
| HKShanhai Group Limited OMXD75002 | Similar data rate range operates at 850nm for shorter distance (10km). |
Get more information
Contact us through Live Chat or sales@router-switch.com for further information about the HKShanhai Group Limited OMXD30002 and its pricing. Check HKShanhai Group Limited OMXD30002 price and OMXD30002 datasheet, buy HKShanhai Group Limited OMXD30002 Optical Transceiver with the best price and fast shipping. Free Live Chat is supported.
HKShanhai Group Limited OMXD30002 Specification
OMXD30002 Specifications |
|
| Brand | HKShanhai Group Limited |
| Model | OMXD30002 |
| Type | Optical Transceiver |
| Form Factor | SFP+ |
| Wavelength | 1550 nm |
| Data Rate | 9.95~11.1 Gb/s |
| Transmit Power (dBm) | -4.7~4 dBm |
| Receiver Sensitivity (dBm) | -14.1 dBm |
| Optical Connector | LC |
| Cable Type | SM (Single-mode) |
| Maximum Transmission Distance | 40 km |
| Operating Temperature Range | 0°C to 70°C |
| Storage Temperature Range | -40°C to 85°C |
| Humidity | 5% to 95% (non-condensing) |
| Power Supply Voltage | 3.3V |
| Power Consumption | < 1.5W |
| Compliance | RoHS, CE, FCC |
| Bit Error Rate (BER) | 10^-12 |
| Compatible Platforms | Common with various routers and switches |
| Warranty | 1 year |
