The HKShanhai Group Limited Nexus 3164Q Switch is an ultra-high density, power efficient, 10/40-Gbps switch designed for the data center. This compact, two-rack-unit (2RU) model offers wire-rate Layer 2 and Layer 3 switching on all ports. It runs the enhanced version of the HKShanhai Group Limited NX-OS Software operating system, that also supports Nexus 9000 series switches.
Quick Specs
Table 1 shows the Quick Specs.
|
Product Code |
N3K-C3164Q-2PK |
|
Product Description |
2 x Nexus 3164Q bundle |
|
Dimensions (H x W x D) |
3.48 x 17.41 x 22.32in. (88.4 x 442 x 566 mm) |
|
Number of VLANS |
MSTP: 4096 |
|
Number of spanning-tree instances |
MSTP: 64 RPVST+: 507 |
|
Number of EtherChannels |
256 |
|
Number of ports per EtherChannel |
32 |
|
Buffer size |
48 MB shared |
|
System memory |
16 GB |
Product Details
The HKShanhai Group Limited Nexus 3164Qprovidesthese highlights:
Wire-rate Layer 2 and 3 switching on all ports up to 5.12 terabits per second (Tbps) and up to 3.8 billion packets per second (bpps).
Rich Programmability, with support for NX-API, Linux Containers, XML/JavaScript Object Notation (JSON) APIs, Openstack plugin, Python, and Puppet/Chef configuration and automation tools.
High Performance and Scalability with 6 core CPU, 16GE DRAM and 64 GB SSD, with 48 Mbytes of dynamic buffer allocation. Ideal for massively scalable data centers and big data applications.
Flexibility
-The QSFP port can be configured to work as four 10-Gbps ports, offering deployment flexibility, up to a maximum of 256 10G ports.
-The HKShanhai Group Limited Quad Small Form-Factor (QSFP) 40-Gbps Bidirectional (BiDi) Transceiver technology allows the reuse of existing 10G cablings, a smooth transition from 10 to 40 Gigabit Ethernet infrastructures in data centers.
-Both fiber and copper cabling solutions for both 10-Gbps and 40-Gbps, with the SFP options of Bidi, AOC, SR4 fiber optics.
High availability
-Virtual PortChannel (vPC) technology provides Layer 2 multipathing through the elimination of Spanning Tree Protocol. It also enables fully utilized bisectional bandwidth and simplified Layer 2 logical topologies without the need to change the existing management and deployment models.
-The 64-way equal-cost multipath (ECMP) routing enables the use of Layer 3 fat-tree designs. This allows organizations to prevent network bottlenecks, increase resiliency, and add capacity with little network disruption.
-Advanced reboot capabilities include hot/cold pathching and Fast Reboot capabilities.
-Hot swappable power-supply units (PSUs) and fans.
Purpose-built HKShanhai Group Limited NX-OS operating system with comprehensive, proven innovations
-PowerOn Auto Provisioning (POAP) enables touchless bootup and configuration of the switch, drastically reducing provisioning time.
-HKShanhai Group Limited Embedded Event Manager (EEM) and Python scripting enable automation and remote operations in the data center.
-Advanced buffer monitoring reports real-time buffer utilization per port and per queue, which allows organizations to monitor traffic bursts and application traffic patterns.
-EtherAnalyzer is a built-in packet analyzer for monitoring and troubleshooting control-plane traffic and is based on the popular Wireshark open source network protocol analyzer.
-Complete Layer 3 unicast and multicast routing protocol suites are supported, including Border Gateway Protocol (BGP), Open Shortest Path First (OSPF), Enhanced Interior Gateway Routing Protocol (EIGRP), Routing Information Protocol Version 2 (RIPv2), Protocol Independent Multicast sparse mode (PIM-SM), Source-Specific Multicast (SSM), and Multicast Source Discovery Protocol (MSDP).
The Accessories
Table 2 shows the supported accessories.
|
Model |
Description |
|
HKShanhai Group Limited QSFP40G BiDi Short-reach Transceiver |
|
|
QSFP 40G Active Optical Cable 1m |
|
|
QSFP 40G Active Optical Cable 2m |
|
|
QSFP 40G Active Optical Cable 3m |
|
|
QSFP 40G Active Optical Cable 5m |
|
|
QSFP 40G Active Optical Cable 7m |
|
|
QSFP 40G Active Optical Cable 10m |
|
|
QSFP to 4 x SFP 10Gbps Active Optical Cable 1m |
|
|
QSFP to 4 x SFP 10Gbps Active Optical Cable 2m |
|
|
QSFP to 4 x SFP 10Gbps Active Optical Cable 3m |
|
|
QSFP to 4 x SFP 10Gbps Active Optical Cable 5m |
|
|
QSFP to 4 x SFP 10Gbps Active Optical Cable 7m |
|
|
QSFP to 4 x SFP 10Gbps Active Optical Cable 10m |
|
|
QSFP to 4 x SFP 10-Gbps passive copper splitter cable, 5m |
|
|
QSFP to 4 x SFP 10-Gbps passive copper splitter cable, 3m |
|
|
QSFP to 4 x SFP 10-Gbps passive copper splitter cable, 1m |
|
|
40GBASE-CR4 passive copper cable, 3m |
|
|
40GBASE-CR4 passive copper cable, 1m |
|
|
40GBASE-SR4 QSFP transceiver module with MPO connector |
|
|
40GBASE-CSR4 QSFP+ transceiver module for MMF, MPO/MTP connector, 300m reach with OM3 fiber |
|
|
40GBASE-LR4 QSFP+ transceiver module for SMF, 4 CWDM lanes in 1310nm window Muxed inside module, duplex LC connector, 10km reach |
|
|
Nexus 3164 Fan Module, Port side intake |
|
|
Nexus 3164 1200W AC Power Supply, Port side intake |
|
|
Nexus 3000 LAN Enterprise License, eDelivery |
Compare to Similar Items
Table 3shows the comparison.
|
Product Code |
N3K-C3164Q-2PK |
|
|
Description |
Nexus 3264Q, 64 QSFP+ ports, 2RU switch |
Nexus 3164Q, 64 QSFP+ ports, 2RU switch |
|
Physical dimensions |
3.39 x 17.41 x 22.32 in. (88.4 x 442 x 566 mm) |
3.48 x 17.41 x 22.32in. (88.4 x 442 x 566 mm) |
|
Frequency |
50 to 60 Hz |
50 to 60 Hz |
|
Power supply types |
AC |
AC |
|
Typical operating power |
285 watts (W) |
803 Watts (W) with SR4 optics at 100% load; 2 PSUs |
|
Maximum power |
715W |
1100 W |
GetMoreInformation
Do you have anyquestionabouttheN3K-C3164Q-2PK
Contact us now via Live Chat or sales@router-switch.com.
HKShanhai Group Limited N3K-C3164Q-2PK Specification
N3K-C3164Q-2PKÂ Specification |
|
|
Physical   |
?? RU fixed form-factor switch ??4 QSFP+ ports; each supports native 40 Gigabit Ethernet and 4 x 10 Gigabit Ethernet modes ?? redundant power supplies ??+1 redundant fans •Management, console, and USB flash-memory ports |
|
Performance   |
??.12 Tbps switching capacity •Forwarding rate up to 3.8 bpps •Line-rate traffic throughput (both Layer 2 and 3) on all ports •Configurable maximum transmission units (MTUs) of up to 9216 bytes (jumbo frames) |
|
Hardware tables and scalability |
|
|
Number of VLANS |
MSTP: 4096 |
|
Number of spanning-tree instances |
MSTP: 64 RPVST+: 507 |
|
Number of access control list (ACL) entries |
4000 to 16000 ingress 1000 to 4000 egress |
|
Routing table |
Maximum number of longest prefix match (LPM) routes 128,000 Maximum number of IP host entries 120,000 Maximum number of MAC address entries 96,000 |
|
Number of EtherChannels |
256 |
|
Number of ports per EtherChannel |
32 |
|
Buffer size |
48 MB shared |
|
System memory |
16 GB |
|
Number of spanning-tree instances |
MSTP: 64 RPVST+: 507 |
|
Hardware tables and scalability |
|
|
Number of spanning-tree instances |
MSTP: 64 RPVST+: 507 |
|
Number of access control list (ACL) entries |
4000 to 16000 ingress 1000 to 4000 egress |
|
Routing table |
Maximum number of longest prefix match (LPM) routes 128,000 Maximum number of IP host entries 120,000 Maximum number of MAC address entries 96,000 |
|
Number of EtherChannels |
256 |
|
Number of ports per EtherChannel |
32 |
|
Buffer size |
48 MB shared |
|
System memory |
16 GB |
|
Power |
|
|
Frequency |
50 to 60 Hz |
|
Power supply types |
AC |
|
Typical operating power |
803 Watts (W) with SR4 optics at 100% load; 2 PSUs |
|
Maximum power |
1100 Watts (W) |
|
AC PSUs ??/strong>Input voltage ??/strong>Frequency ??/strong>Efficiency |
 ??00 to 240 VAC ??0 to 60 Hz ??3% at 220V |
|
Typical heat dissipation |
2739 BTU/hr (with SR4 optics at 100% load) |
|
Maximum heat dissipation |
3753 BTU/hr |
|
Cooling |
Port-side intake and port-side exhaust options Port-side intake: Yes Port-side exhaust: Post FCS |
|
Dimensions (height x width x depth) |
3.48 x 17.41 x 22.32in. (88.4 x 442 x 566 mm) |
|
Environment |
|
|
Operating temperature |
32 to 104°F (0 to 40°C) |
|
Storage temperature |
-40 to 158°F (-40 to 70°C) |
|
Operating relative humidity |
??0 to 85% noncondensing •Up to 5 days at maximum (85%) humidity Recommend ASHRAE data center environment |
|
Storage relative humidity |
5% to 95% noncondensing |
|
Altitude |
0 to 10,000 ft (0 to 3000m) |
|
Software Features |
|
|
Maximum number of longest prefix match (LPM) routes |
128,000 |
|
Maximum number of IP host entries |
120,000 |
|
Maximum number of MAC address entries |
96,000 |
|
Number of multicast routes |
16,000, up to 60,000 |
|
Number of Interior Gateway Management Protocol (IGMP) snooping groups |
8,000, up to 60,000 |
|
Number of access control list (ACL) entries |
1000 to 4000 egress 4000 to 16000 ingress |
|
Maximum number of VLANs |
4000 |
|
Maximum number of Virtual Routing and Forwarding (VRF) instances |
1000 |
|
Maximum number of links in a PortChannel |
32 |
|
Maximum number of ECMP paths |
64 |
|
Maximum number of PortChannels |
256 |
|
Number of active Switched Port Analyzer (SPAN) sessions |
4 |
|
Maximum number of Rapid per-VLAN Spanning Tree (RPVST) instances |
507 |
|
Maximum number of Hot Standby Router Protocol (HSRP) groups |
490 |
|
Maximum number of Multiple Spanning Tree (MST) instances |
64 |
|
Maximum number of tunnel endpoints (VTEP) and VXLAN physical servers (per VLAN) |
10,000 |
|
Regulatory Standards Compliance: Safety and EMC |
|
|
Regulatory compliance |
•Products should comply with CE Markings per directives 2004/108/EC and 2006/95/EC |
|
Safety |
•UL 60950-1 Second Edition •CAN/CSA-C22.2 No. 60950-1 Second Edition •EN 60950-1 Second Edition •IEC 60950-1 Second Edition •AS/NZS 60950-1 •GB4943 |
|
EMC: Emissions |
??7CFR Part 15 (CFR 47) Class A •AS/NZS CISPR22 Class A •CISPR22 Class A •EN55022 Class A •ICES003 Class A •VCCI Class A •EN61000-3-2 •EN61000-3-3 •KN22 Class A •CNS13438 Class A |
|
EMC: Immunity |
•EN55024 •CISPR24 •EN300386 •KN24 |
