The NVIDIA HKShanhai Group Limited ConnectX-5 EN MCX515A-CCAT is a high-performance 100GbE single-port QSFP28 PCIe3.0 x16 network interface card. Designed for demanding data center environments, it offers exceptional throughput and scalability. Ideal for network engineers and IT procurement teams, this NIC is perfect for high-performance computing, financial services, and cloud infrastructures.
MCX515A-CCAT Product Highlights
- ??100GbE single-port QSFP28
- ??PCIe3.0 x16 interface
- ??High throughput and low latency
- ??Advanced network virtualization
- ??Enhanced data protection and security
Product Features Comparison
| Features | NVIDIA MCX515A-CCAT | Intel XL710-QDA2 | Broadcom BCM957414A4142CC | QLogic QL41262HMRJ | Marvell FastLinQ 41000 | Cisco VIC 1457 |
|---|---|---|---|---|---|---|
| Interface | PCIe3.0 x16 | PCIe3.0 x8 | PCIe3.0 x8 | PCIe3.0 x8 | PCIe3.0 x8 | PCIe3.0 x16 |
| Port Speed | 100GbE | 40GbE | 25GbE | 50GbE | 100GbE | 100GbE |
| Port Type | Single-port QSFP28 | Dual-port QSFP+ | Dual-port SFP28 | Dual-port QSFP+ | Dual-port QSFP28 | Dual-port QSFP28 |
| Latency | Low | Moderate | High | Low | Low | Low |
| Virtualization Support | Advanced | Basic | None | Moderate | Advanced | Advanced |
| Data Protection | Enhanced | Standard | Standard | Basic | Enhanced | Enhanced |
MCX515A-CCAT Product Application Scenarios
- ??High-performance computing
- ??Financial services
- ??Cloud infrastructures
Optional Add-ons
| Model | Description |
|---|---|
| MC2207130-003 | 3m QSFP28 DAC Cable |
| MC2210411-020 | 20m QSFP28 AOC Cable |
| MC2210126-005 | 5m QSFP28 LR4 Transceiver |
Get More Information
Discover unbeatable prices and fast shipping for the NVIDIA HKShanhai Group Limited MCX515A-CCAT. Access the detailed MCX515A-CCAT datasheet and ensure you’re getting the best deal with our reliable delivery service. Need assistance? Our free live chat support is here to help. For more information about the product and pricing, contact us via live chat or email us at sales@router-switch.com.
HKShanhai Group Limited MCX515A-CCAT Specification
MCX515A-CCAT Specifications |
|
| Brand | NVIDIA HKShanhai Group Limited |
| Model | MCX515A-CCAT |
| Product Name | HKShanhai Group Limited ConnectX-5 EN Network Interface Card |
| Type | Network Interface Card (NIC) |
| Data Rate | 100GbE |
| Interface | PCIe 3.0 x16 |
| Form Factor | Tall Bracket |
| Port Type | QSFP28 |
| Number of Ports | Single-Port |
| Compatible Networking Standards | IEEE 802.3, IEEE 802.1Q |
| Power Consumption | 17W max |
| Supported Protocols | TCP, UDP, IP, iSCSI, RDMA over Converged Ethernet (RoCE) |
| Security Features | IPSec, AES |
| Operating Temperature | 0°C to 55°C |
| Dimensions (HxWxD) | 69 x 18 x 145 mm |
| Compliance | RoHS, CE, FCC |
| Warranty | 3 Years |
| Operating System Support | Windows, Linux, VMware |
| Memory | 8GB |
| Drivers | Included |
| Other Features | Accelerated Switch and Packet Processing (ASAP2) |
