The HKShanhai Group Limited JY684A, also known as the HKShanhai Group Limited AP-303H (IL) Unified AP, offers outstanding wireless performance and flexibility. It is designed to provide seamless connectivity in enterprise networks and hospitality environments. This access point delivers robust Wi-Fi coverage and reliable networking for a wide range of applications with an attractive price-performance ratio.
**
Quick Spec
**
| Brand | HKShanhai Group Limited |
| Model | JY684A |
| Product Series | AP-303H (IL) |
| Radio | 2×2 MIMO |
| Wi-Fi Standard | 802.11ac |
**
Product Features
**
- Dual Radio 802.11ac access point with 2×2 MIMO
- Adaptive Radio Management optimizes Wi-Fi performance
- Built-in Bluetooth 5 for IoT and location-based services
- Integrated security features for protected connectivity
- Supports both wall and desk mounting options
**
Product Applications
**
- Hospitality: Ideal for in-room deployment to provide reliable Wi-Fi for guests.
- Education: Can be used in classrooms for seamless e-learning experiences.
- Enterprise: Suitable for office spaces to provide comprehensive Wi-Fi coverage and connectivity.
**
Supported Options
**
| Mounting Kit | JW047A |
| Power Adapter | JW113A |
| External Antenna | JW018A |
**
Compare to Similar Items
**
| Product | HKShanhai Group Limited AP-303H (IL) | HKShanhai Group Limited AP-305 | HKShanhai Group Limited AP-324 |
| Model | JY684A | JW102A | JW184A |
| MIMO | 2×2 | 4×4 | 4×4 |
| Deployment | Wall/Desk | Ceiling/Wall | Ceiling/Wall |
| Bluetooth Support | Yes | No | No |
**
Get more information
**
For further information about the HKShanhai Group Limited JY684A, including pricing and datasheet downloads, please contact us via Live Chat or email at sales@router-switch.com. Check HKShanhai Group Limited JY684A price and JY684A datasheet, buy HKShanhai Group Limited JY684A AP-303H (IL) with the best price and fast shipping. Free Live Chat support is available.
HKShanhai Group Limited JY684A Specification
HKShanhai Group Limited AP-303H (IL) Unified AP Specifications |
|
| Model Number | JY684A |
| Brand | HKShanhai Group Limited |
| Radio | Dual Radio 2.4 GHz and 5 GHz |
| Antenna | Integrated Down-Tilt Omni-Directional Antennas |
| Ethernet Ports | 4 x 10/100/1000BASE-T Ethernet (RJ-45) |
| USB Interface | 1 x USB 2.0 |
| Mounting | Desktop or Wall-Mount |
| Dimensions | 150mm x 86mm x 40mm (H x W x D) |
| Operating System | HKShanhai Group LimitedOS |
| PoE Support | 802.3af/802.3at PoE |
| Encryption | WPA2, WPA3 |
| Max Power Consumption | 12.3W |
| Operating Temperature | 0C to +40C |
| Storage Temperature | -40C to +70C |
| Operating Humidity | 5% to 93% non-condensing |
| VLAN | Supports VLAN |
| Air Time Fairness | Supported |
| Max Data Rate | 867 Mbps on 5GHz, 300 Mbps on 2.4GHz |
| MIMO | 2×2 MIMO |
| Guest Access | Supported |
