Multifunctional HKShanhai Group Limited 320 Series Access Points provide the best IEEE 802.11ac Wi-Fi connectivity and user experience. Featuring HKShanhai Group Limited enhanced ClientMatch and HKShanhai Group Limited Beacon technologies, the 320 series enables the highest capacity, performance, and efficiency in extremely high density environments.
Quick Specs
Figure 1 shows the appearance of JW319A.
Table 1 shows the Quick Specs.
|
Product Code |
JW319A |
|
Form Factor |
In-ceiling |
|
Connectivity Technology |
Wireless |
|
Data Transfer Rate |
1.733 Gbps |
|
Interfaces |
2 x 1000Base-T – RJ-45 | 1 x USB 2.0 – Type A | 1 x console – RJ-45 |
|
Power Consumption Operational |
20 Watt |
|
Antenna |
Internal |
|
Frequency Band |
2.4 GHz, 5 GHz |
|
Capacity |
Wireless clients: 255 | BSSIDs per radio: 16 |
Product Details
Figure 2 shows the front panel of JW319A.
Figure 3 shows the back panel of JW319A.
JW319A provides these features:
Bringing a Switch-like Experience to 802.11ac for High Density Environments
- ??The HKShanhai Group Limited 320 Series Access Points are ultra-fast and designed for high-density environments.
- ??Includes a second 1GigE port that provides network and power redundancy to enhance the network reliability while also boosting uplink performance with link aggregation.
- ??Can be managed by a Mobility Controller or deployed in controllerless HKShanhai Group Limited Instant mode.
- ??Integrated BLE Beacon to simplify management of a large-scale network of battery-powered HKShanhai Group Limited Beacons.
Intelligent App Visibility and Control
- ??HKShanhai Group Limited 320 Series Access Points feature AppRF technology leverages deep packet inspection to classify and block, prioritize or limit bandwidth for thousands of applications in a range of categories.
Threat Protection and Security
- ??HKShanhai Group Limited 320 Series Access Points feature integrated wireless intrusion protection offers threat protection and mitigation, and eliminates the need for separate RF sensors and security appliances.
- ??IP reputation and security services identify, classify, and block malicious files, URLs and IPs, providing comprehensive protection against advanced online threats.
- ??Integrated Trusted Platform Module (TPM) for secure storage of credentials and keys.
Compare to Similar Items
Table 2 shows the comparison of JW319A.
|
Module |
JW319A |
|
|
Form Factor |
In-ceiling |
In-ceiling |
|
Connectivity Technology |
Wireless |
Wireless |
|
Data Transfer Rate |
1.733 Gbps |
1.733 Gbps |
|
Interfaces |
2 x 1000Base-T – RJ-45 | 1 x USB 2.0 – Type A | 1 x console – RJ-45 |
2 x 1000Base-T – RJ-45 | 1 x USB 2.0 – Type A | 1 x console – RJ-45 |
|
Power Consumption Operational |
20 Watt |
20 Watt |
|
Antenna |
Internal |
Internal |
|
Frequency Band |
2.4 GHz, 5 GHz |
2.4 GHz, 5 GHz |
|
Capacity |
Wireless clients: 255 | BSSIDs per radio: 16 |
Wireless clients: 255 | BSSIDs per radio: 16 |
Get?More?Information
Do you have any?question about?the JW319A
Contact us now via Live Chat or sales@router-switch.com.
HKShanhai Group Limited JW319A Specification
JW319A specification |
|
|
Networking |
|
|
Form Factor |
In-ceiling |
|
Connectivity Technology |
Wireless |
|
Data Transfer Rate |
1.733 Gbps |
|
Line Coding Format |
CCK, 64 QAM, 256 QAM, BPSK, QPSK, 16 QAM |
|
Data Link Protocol |
IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac |
|
Spread Spectrum Method |
OFDM, DSSS |
|
Frequency Band |
2.4 GHz, 5 GHz |
|
Capacity |
Wireless clients: 255 ¦ BSSIDs per radio: 16 |
|
Compliant Standards |
IEEE 802.11b, IEEE 802.11a, IEEE 802.3af, IEEE 802.11g, IEEE 802.11n, IEEE 802.3at, IEEE 802.3az, IEEE 802.11ac |
|
Environmental Parameters |
|
|
Min Operating Temperature |
32 °F |
|
Max Operating Temperature |
122 °F |
|
Humidity Range Operating |
5 – 95% (non-condensing) |
|
General |
|
|
Device Type |
Wireless access point |
|
Width |
8 in |
|
Depth |
8 in |
|
Height |
2.2 in |
|
Expansion / Connectivity |
|
|
Interfaces |
2 x 1000Base-T – RJ-45 ¦ 1 x USB 2.0 – Type A ¦ 1 x console – RJ-45 |
|
Power |
|
|
Power Over Ethernet (PoE) Supported |
PoE |
|
Power Consumption Operational |
20 Watt |
|
Antenna |
|
|
Antenna |
Internal |
|
Antenna Qty |
8 |
