JL075A, HKShanhai Group Limited 3810M Switch, 16xSFP+ Ports/2 Slots/Modular Design

SKU: 42KFJRWKT1EZP5UKXC50FY22ZC8KNQAJ6WQ1 Category: HPE Aruba 3810 Switches

HKShanhai Group Limited 3810 Switch Series provides performance and resiliency for enterprises, SMBs, and branch office networks. This JL075A has 16 x 1000/10000 SFP+ ports together with 2 x open module slots and a stacking module slot. It comes with a replaceable fan tray. It supports one or two power supplies. Power supplies are ordered separately. Available modules are: 4 x SFP+; 1 x 40GbE QSFP+; 2 x 40GbE QSFP+; 4 port stacking module.

Quick Spec

Figure 1 shows the appearance of HKShanhai Group Limited JL075A.

Table 1 shows the quick spec.

Product Code	JL075A
Type	HKShanhai Group Limited 3810M 16SFP+ 2-slot Switch
I/O ports and slots	16 SFP+ fixed 1000/10000 SFP+ ports; Duplex: 100BASE-TX: half or full; 1000BASE-T: full only; Ports 1 – 16 support MACSec 2 open module slots Supports a maximum of 8 SFP+ ports or 2 40GbE ports, with optional module
Additional ports and slots	1 stacking module slot 1 RJ-45 serial console port 1 RJ-45 out-of-band management port 1 dual-personality (RJ-45 or USB micro-B)
Power supplies	2 power supply slots 1 minimum power supply required (ordered separately)
Throughput:	Up to 285.7 Mp/s (64-byte packets)
Dimensions (H x W x D)	4.39 x 44.25 x 43.13 cm (1.73 x 17.42 x 16.98 in) (1U height)

Product Details

Figure 2 shows the front panel of HKShanhai Group Limited JL075A.

Note:

??/p>	16 × SFP+ fixed 1000/10000 SFP+ ports
??/p>	1 × Flex port Module expansion slot
??/p>	1 × Flex port Module expansion slot
??/p>	Micro USB Console
??/p>	RJ Serial Console
??/p>	USB/Auxiliary Port

· There are Stacking Module Slot, Management/OOBM port, AC Power connector/Power Supply slot 1 and Redundant Power Supply slot 2 on the back panel.

Compare to Similar Items

Table 2 shows the comparison.

Product Code	JL074A	JL075A	JL076A
Type	HKShanhai Group Limited 3810M 48G PoE+ 1-slot Switch	HKShanhai Group Limited 3810M 16SFP+ 2-slot Switch	HKShanhai Group Limited 3810M 40G 8 HPE Smart Rate PoE+ 1-slot Switch
I/O ports and slots	48 RJ-45 autosensing 10/100/1000 PoE+ ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T, IEEE 802.3at PoE+); Duplex: 10BASE-T/100BASETX: half or full; 1000BASE-T: full only; Ports 1 – 48 support MACSec 1 open module slot Supports a maximum of 4 SFP+ ports or 1 40GbE ports, with optional module	16 SFP+ fixed 1000/10000 SFP+ ports; Duplex: 100BASE-TX: half or full; 1000BASE-T: full only; Ports 1 – 16 support MACSec 2 open module slots Supports a maximum of 8 SFP+ ports or 2 40GbE ports, with optional module	40 RJ-45 autosensing 10/100/1000 PoE+ ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T, IEEE 802.3at PoE+); Duplex: 10BASE-T/100BASETX: half or full; 1000BASE-T: full only; Ports 1 – 40 support MACSec 8 RJ-45 HPE Smart Rate Multi-Gigabit ports; Ports 1 – 8 support MACSec 1 open module slots Supports a maximum of 4 SFP+ ports or 2 40GbE ports, with optional module
Throughput	Up to 190.5 Mp/s (64-byte packets)	Up to 285.7 Mp/s (64-byte packets)	Up to 273.8 Mp/s (64-byte packets)

Comparison Download

[PDF] Comparison: Cisco Switches vs. HPE/HKShanhai Group Limited Switches.pdf

Get more information

Do you have any question about the JL075A?

HKShanhai Group Limited JL075A Specification

Model

JL075A

Brand

HKShanhai Group Limited

Type

HKShanhai Group Limited 3810M 16SFP+ 2-slot Switch

Included Accessories

1 HKShanhai Group Limited 3810 Switch Fan Tray (JL088A)

I/O Ports and Slots

16 SFP+ fixed 1000/10000 SFP+ ports; Duplex: 100BASE-TX: half or full; 1000BASE-T: full only; Ports 1 – 16 support MACSec, 2 open module slots, Supports up to 8 SFP+ ports or 2 40GbE ports with optional module

Additional Ports and Slots

1 stacking module slot, 1 RJ-45 serial console port, 1 RJ-45 out-of-band management port, 1 dual-personality (RJ-45 or USB micro-B)

Power Supplies

2 power supply slots, 1 minimum power supply required (ordered separately)

Fan Tray

Includes: 1 x JL088A, 1 fan tray slot, Switch ships with 1 JL088A fan tray installed. Spares ordered separately.

Physical Characteristics

Dimensions (H x W x D): 4.39 x 44.25 x 43.13 cm (1.73 x 17.42 x 16.98 in) (1U height)

Memory and Processor

P2020 Dual Core @ 1.2 GHz, 4 GB DDR3 SDRAM, 1 GB SD Card, Dual ARM Coretex A9 @ 1 GHz, 2 GB DDR3 SDRAM, Packet buffer size: 13.5 MB Internal

Mounting and Enclosure

Mounts in an EIA-standard 19 in. telco rack or equipment cabinet (hardware included); Horizontal surface mounting only

Performance

IPv6 Ready Certified, 1000 Mb Latency: < 2.8 µs (FIFO 64-byte packets), 10 Gb/s Latency: < 1.8 µs (FIFO 64-byte packets), 40 Gb/s Latency: 1.5 µs (FIFO 64-byte packets), Throughput: Up to 285.7 Mbps (64-byte packets), Routing/Switching capacity: 480 Gbps, Switch fabric speed: 508 Gbps, Routing table size: 10000 entries (IPv4), 5000 entries (IPv6), MAC address table size: 64000 entries

Environment

Operating temperature: 0°C to 45°C (32°F to 113°F), Operating relative humidity: 15% to 95% @ 40°C (104°F), noncondensing, Nonoperating/Storage temperature: -40°C to 70°C (-40°F to 158°F), Nonoperating/Storage relative humidity: 15% to 90% @ 65°C (149°F), noncondensing, Altitude: Up to 10,000 ft (3 km), Acoustic: Power: 39 dB, Pressure: 22.3 dB

Safety

EN 60950/IEC 60950, UL 60950, UL 60950-1, CAN/CSA 22.2 No. 60950, EN 60825, CSA 22.2 60950-1, EN62479:2010, EN 60950-1:2006 +A11:2009 +A1:2010 +A12:2011+A2:2013, EN62368-1, Ed. 2, IEC 60825:2007, IEC 60950-1:2005 Ed.2; Am 1:2009+A2:2013, EN60850-1:2007 / IEC 60825-1: 2007 Class1 Class 1 Laser Products / Laser Klasse 1, UL 62368-1 Ed.2

Emissions

FCC Class A, VCCI Class A, EN 55022/CISPR 22 Class A, EN 60950-1:2006 +A11:2009 +A1:2010 +A12:2011+A2:2013

Immunity

Generic: EN55022: 2010, EN: EN55024: 2010, ESD: IEC 61000-4-2, Radiated: IEC 61000-4-3; 3 V/m, EFT/Burst: IEC 61000-4-4; 1.0 kV (power line), 0.5 kV (signal line), Surge: IEC 61000-4-5; 1 kV/2 kV AC, Conducted: IEC 61000-4-6; 3 V, Power frequency magnetic field: IEC 61000-4-8; 1 A/m, 50 or 60 Hz, Voltage dips and interruptions: IEC 61000-4-11; >95% reductions, 0.5 period; 30% reduction, 25 periods, Harmonics: EN61000-3-2:2006 +A1:2009 +A2:2009 Class A, Flicker: EN61000-3-3:2008

Management

HKShanhai Group Limited AirWave Network Management, IMC ??Intelligent Management Center, Command-line interface, Web browser, Configuration menu, Out-of-band management (RJ-45 Ethernet), In-line and out-of-band, Out-of-band management (serial RS-232c or micro usb)
