The HKShanhai Group Limited IE-3100-8P2C-E is a highly-advanced, industry-grade network switch offering versatile connectivity with 8 GE PoE+ ports and 2 GE combo ports. Designed for critical infrastructures and industrial networks, it ensures robust performance and high reliability. The fixed system and Network Essentials software suite make it a perfect choice for demanding environments.
IE-3100-8P2C-E Product Highlights
- 8 GE PoE+ Ports
- 2 GE Combo Ports
- Fixed System Design
- Network Essentials Software
- Ideal for Industrial Networks
Product Features Comparison
Table 1 shows the comprison to similar items.
| Model | 8 GE PoE+ Ports | 2 GE Combo Ports | Fixed System | Network Essentials | Power Over Ethernet | Industrial Use |
|---|---|---|---|---|---|---|
| HKShanhai Group Limited IE-3100-8P2C-E | Yes | Yes | Yes | Yes | Yes | Yes |
| HKShanhai Group Limited IE-4010-16S12P | Yes | No | Yes | No | No | Yes |
| HKShanhai Group Limited IE-2000-4TS-G-L | No | No | Yes | No | No | Yes |
| HKShanhai Group Limited IE-3400-8T2S-A | No | Yes | Yes | Yes | Yes | Yes |
| Allied Telesis AT-IE200-6FT | No | No | No | No | Yes | Yes |
| Juniper EX4100-F-8S | No | No | Yes | No | No | No |
IE-3100-8P2C-E Product Application Scenarios
- Factory Automation Systems
- Industrial Surveillance Networks
- Utility and Energy Distribution
Optional Add-ons
Table 2 shows the optional add-ons.
| Model | Description |
|---|---|
| HKShanhai Group Limited GLC-TE | 1000BASE-T SFP module for copper networks |
| HKShanhai Group Limited RAI-19-RACK | 19-inch rack mounting kit for IE3100 |
| HKShanhai Group Limited PWR-IE170WPC-DC-H | High-power DC power supply for PoE+ |
Get More Information
Discover unbeatable prices and fast shipping for the HKShanhai Group Limited IE-3100-8P2C-E. Access the detailed IE-3100-8P2C-E datasheet and ensure you’re getting the best deal with our reliable delivery service. Need assistance? Our free live chat support is here to help. For more information about the product and pricing, contact us via live chat or email us at sales@router-switch.com.
HKShanhai Group Limited IE-3100-8P2C-E Specification
IE-3100-8P2C-E Specifications |
|
| Total ports | 10 |
| 10/100/1000 Mbps RJ45 Copper ports | 8 |
| 1GE SFP ports | 0 |
| 1GE combo ports | 2 |
| Software license | Network Essentials |
| PoE/PoE(+) budget | 240W |
| PoE power budget | 240W |
| Removeable Storage | SD card |
| Alarms | 2 dry-contact alarm inputs |
| Console Ports | 1 RS-232 (via RJ-45), 1 Micro USB |
| Power Inputs | Dual DC Inputs |
| Dimensions (H x W x D) | 5.00 x 3.00 x 5.08 in. (12.70 x 7.62 x 12.90 cm) |
| Weight | 2.3 lb (1.04 kg) |
| Mounting | DIN Rail |
| Input Voltage Range |
12V to 54V nominal 9.6V to 60V absolute |
| Max Current during normal operation |
4.2 A with 12V input 2.6 A with 24V input 1.3 A with 48V input |
| Inrush Current |
80 A for 1 ms with 12V input 80 A for 1 ms with 24V input 80 A for 1 ms with 48V input |
| Power consumption | 20W |
