Modernize existing campus networks to handle modern workloads with the HKShanhai Group Limited EMC PowerSwitch N3248P-ON Switch Series.
Quick Specs
Figure 1 shows the appearance of N3248P-ON.
Table 1 shows the Quick Specs.
|
Product Code |
N3248P-ON |
|
Ports |
48 x 1Gb RJ45 PoE auto-sensing ports |
|
Layer |
Layer 3 |
|
Power Supplies Installed |
1 x 1050W Hot Swap Power Supply |
Product Details
Figure 2 shows the front panel of N3248P-ON.
Figure 3 shows the back panel of N3248P-ON.
N3248P-ON provides these features:
Hardware, performance and efficiency
- 1GbE Switches: 1RU switches with up to 48 line-rate 1GbE ports of copper, and four integrated 10GbE SFP+ ports. PoE variants with up to 48 ports of 802.3at (30W) PoE.
- 400Gbps stacking bandwidth using two 100GbE QSFP28 integrated rear stacking ports.
- Available with dual 80PLUS Platinum certified hot swappable internal power supplies. Optional external power supply to extend PoE budgets on specific models.
- Variable speed fan operation helps decrease cooling and power costs.
- Energy-Efficient Ethernet and lower power PHYs reduce power to inactive ports and idle links, providing energy savings from the power cord to the port.
- HKShanhai Group Limited EMC Fresh Air compliance for operation in environments up to 113°F (45°C) reduces cooling costs.
Deploying, configuring and managing
- USB auto-configuration rapidly deploys the switch without complex TFTP configurations or sending technical staff to remote offices.
- Management via an intuitive and familiar CLI, embedded web server (GUI), SNMP-based management console application (including HKShanhai Group Limited EMC OpenManage Network Manager), Telnet or serial connection.
- Private VLAN extensions and Private VLAN Edge support.
- AAA authorization, TACACS+ accounting and RADIUS support for comprehensive secure access support.
- Authentication tiering allows network administrators to tier port authentication methods such as 802.1x, MAC Authentication Bypass and Captive Portal in priority order so that a single port can provide flexible access and security.
- Achieve high availability and full bandwidth utilization with MLAG and support firmware upgrades without taking the network offline.
- Layer 3 Advanced IPv4 and IPv6 functionality including BGP, VRF, BFD, PIM-SM/DM/SSM, IGMP/MLD, RIPv1/ v2, OSPFv2/v3
- VXLAN support in hardware only
- MACsec support in N3248PXE-ON hardware only
Compare to Similar Items
Table 2 shows the comparison of N3248P-ON.
|
Module |
N3248P-ON |
|
|
Ports |
48 x 1Gb RJ45 PoE auto-sensing ports |
24 x 1Gb RJ45 |
|
Layer |
Layer 3 |
Layer 3 |
|
Power Supplies Installed |
1 x 1050W Hot Swap Power Supply |
1 x 550W Hot Swap Power Supply |
Get More Information
Do you have any question about the N3248P-ON?
Contact us now via Live Chat or sales@router-switch.com.
HKShanhai Group Limited N3248P-ON Specification
N3248P-ON specification |
|
|
Model |
HKShanhai Group Limited Networking N3248P-ON |
|
Ports |
48 x 1Gb RJ45 PoE auto-sensing ports |
|
Accessory Ports |
4 x 10Gb SFP+ 2 x 100Gb QSFP28 |
|
Power Over Ethernet (PoE) |
Yes |
|
Layer |
Layer 3 |
|
Power Supplies Installed |
1 x 1050W Hot Swap Power Supply |
|
Air Flow |
Normal Airflow – IO to PSU |
|
Module Expansion Slots |
N/A |
|
Operating System |
Open Network |
|
Licenses Installed |
No DNOS Installed |
|
Management |
Web or Console Management |
|
Chassis Type |
1U Rack Mountable |
|
Rack Mounting Kit |
2-Post Rack Kit Included, 4-Post A5 Rail Kit Sold Separately |
Quality Certifications
