The Dahua IPC-HDBW2231R-ZS-S2 is a high-performance 2MP WDR IR Dome Network Camera designed for versatile security applications. It excels in delivering high-quality imagery even in challenging light conditions and incorporates advanced motion detection and abnormality diagnostic features. This network camera ensures comprehensive monitoring with high reliability and efficiency.
Quick Spec
| Resolution | 2MP |
| Lens Type | Motorized Varifocal |
| IR Distance | Up to 30m |
| WDR | 120 dB |
| Power Supply | 12V DC/PoE |
Product Features
- 2 Megapixel resolution for detailed image clarity
- Wide Dynamic Range (WDR) capabilities to handle various lighting conditions
- IR illumination up to a distance of 30 meters for night surveillance
- Multiple abnormality detections including motion, tampering, and voltage issues
- Support for micro SD card slot with error detection features
Product Applications
- Retail stores: Enhanced security monitoring against theft and other illicit activities
- Office buildings: Ensuring the safety of employees and assets with comprehensive surveillance
- Parking lots: Monitoring vehicles and ensuring safety in parking areas
Supported Options
| Wall Mount | PFB203W |
| Ceiling Mount | PFA152-E |
| Junction Box | PFA137 |
Compare to Similar Items
| Model | Difference |
| Dahua IPC-HDBW2231R-ZAS | Includes audio interface for communication |
| Dahua IPC-HDBW2421R-ZS | 4MP resolution for higher image quality |
| Dahua IPC-HDW2231R-ZS | Different form factor with a turret design |
Get more information
For further information about the Dahua IPC-HDBW2231R-ZS-S2, including its price and availability, please contact us through Live Chat or email us at sales@router-switch.com. Check Dahua IPC-HDBW2231R-ZS-S2 price and IPC-HDBW2231R-ZS-S2 datasheet, buy Dahua IPC-HDBW2231R-ZS-S2 Camera with best price and fast shipping. Free Live Chat is supported.
Dahua HDBW2231R-ZS-S2 Specification
IPC-HDBW2231R-ZS-S2 Specifications |
|
| Brand | Dahua |
| Product Name | IPC-HDBW2231R-ZS-S2 |
| Camera Type | Network Camera |
| Image Sensor | 1/2.8�� 2Megapixel progressive CMOS |
| Effective Pixels | 1920(H) x 1080(V) |
| Scanning System | Progressive |
| Minimum Illumination | 0.005 Lux@F1.6 (Color); 0 Lux with IR |
| IR Distance | Up to 50 meters (164 feet) |
| Lens Type | Motorized / Auto Iris (HALL) |
| Lens Mount | ��14 |
| Max. Aperture | F1.6 |
| Field of View | Horizontal: 104��~30��, Vertical: 57��~17�� |
| Video Compression | H.265, H.264, H.264H, MJPEG |
| Resolution | 2MP (1920 x 1080) |
| Frame Rate | Main Stream: 1080P (1~25/30fps); Sub Stream: D1 (1~25/30fps) |
| Bit Rate | H.265: 14Kbps ~ 7424Kbps, H.264: 24Kbps ~ 10240Kbps |
| Audio Interface | 1/1 channel In/Out |
| Alarm Interface | 2/1 channel In/Out |
| Networking | Ethernet (100Base-TX) |
| Storage | Micro SD card (up to 128GB) |
| Power Supply | DC12V, PoE (IEEE 802.3af) |
| Abnormality Detection | Motion detection, video tampering, no SD card, SD card full, SD card error, network disconnected, IP conflict, illegal access, voltage detection |
