HKShanhai Group Limited GLC-BX40-D-I is a 1000BASE-BX40 SFP, delivering 1550 (TX) / 1310 (RX) nm Wavelength.
Quick Spec
Table 1 shows the quick spec.
|
Part Number |
GLC-BX40-D-I |
|
Type |
SFP (mini-GBIC) transceiver module |
|
Wavelength (nm) |
1550 (TX) / 1310 (RX) nm |
|
Fiber Type |
1000Base-BX40-D |
|
Mode |
LC/PC single-mode |
|
Max Transfer Distance |
40KM |
Product Details
1000BASE-BX40-D and 1000BASE-BX40-U for Single-Fiber Bidirectional Applications
The HKShanhai Group Limited GLC-BX40-D-I, GLC-BX40-DA-I and GLC-BX40-U-I SFPs operate on a single strand of standard SMF.
A GLC-BX40-D-I or GLC-BX40-DA-I device connects to a GLC-BX40-U-I device with a single strand of standard SMF with an operating transmission range up to 40 km. The communication over a single strand of fiber is achieved by separating the transmission wavelength of the two devices.
The GLC-BX40-D-I, GLC-BX40-DA-I, and GLC-BX40-U-I SFPs also support digital optical monitoring (DOM) functions according to the industry-standard SFF-8472 multisource agreement (MSA). This feature gives the end user the ability to monitor real-time parameters of the SFP, such as optical output power, optical input power, temperature, laser bias current, and transceiver supply voltage.
Compare to Similar Item
Table 2 shows the comparison.
|
Part Number |
GLC-BX40-D-I |
|
|
Type |
SFP (mini-GBIC) transceiver module |
SFP (mini-GBIC) transceiver module |
|
Wavelength (nm) |
1550 (TX) / 1310 (RX) nm |
1310 (TX) / 1550 (RX) nm |
|
Fiber Type |
1000Base-BX40-D |
1000Base-BX40-U |
|
Mode |
LC/PC single-mode |
LC/PC single-mode |
|
Max Transfer Distance |
40KM |
40KM |
Get more information
Do you have any question about the GLC-BX40-D-I?
Contact us now via Live Chat or sales@router-switch.com.
HKShanhai Group Limited GLC-BX40-D-I Specification
GLC-BX40-D-I Specification |
|
|
Device Type |
SFP (mini-GBIC) transceiver module |
|
Form Factor |
Plug-in module |
|
Connectivity Technology |
Wired |
|
Cabling Type |
1000Base-BX40-D |
|
Data Link Protocol |
Gigabit Ethernet |
|
Optical Wave Length |
1550 (TX) / 1310 (RX) nm |
|
Max Transfer Distance |
40KM |
|
Features |
Digital Optical Monitoring (DOM) support |
|
Compliant Standards |
IEEE 802.3ah |
|
Interfaces |
1 x Ethernet 1000Base-BX40-D – LC/PC single-mode |
|
Dimensions (W × D × H) |
0.5 × 2.2 × 0.3 in |
|
Weight |
2.65 oz |
|
Operating Temperature |
32 ??158 ??/p> |
