HKShanhai Group Limited GLC-2BX-D= is a Dual-channel 1000BASE-BX10 SFP module for single-strand SMF, delivering 1490-nm TX/1310-nm RX wavelength and two single LC/PC connectors.
Quick Spec
Table 1 shows the quick spec.
|
Part Number |
GLC-2BX-D= |
|
Type |
SFP (mini-GBIC) transceiver module |
|
Wavelength (nm) |
1490 (TX) / 1310 (RX) nm |
|
Fiber Type |
1000Base-BX-D |
|
Connector Type |
LC/PC connectors |
|
Max Transfer Distance |
10KM |
Product Details
2-Channel 1000BASE-BX10-D for Single-Fiber Bidirectional Applications
The 2-channel 1000BASE-BX-D SFP module, also known as Compact SFP, integrates two IEEE 802.3ah 1000BASE-BX10-D interfaces in one SFP module.
The GLC-2BX-D or GLC-2BX-D-I is always connected to two 1000BASE-BX10-U interfaces over two single strands of standard SMF with an operating transmission range up to 10km.
GLC-2BX-D or GLC-2BX-D-I is designed to connect to any standard-based Customer Premises Equipment (CPE) in FTTx links.
Compare to Similar Item
Table 2 shows the comparison.
|
Part Number |
GLC-2BX-D= |
|
|
Type |
2-channel 1000BASE-BX10-D downstream bidirectional single fiber; with DOM |
1000BASE-BX10-D downstream bidirectional single fiber; with DOM |
|
Wavelength (nm) |
1490 (TX) / 1310 (RX) nm |
1490 (TX) / 1310 (RX) nm |
|
Fiber Type |
1000Base-BX-D |
1000Base-BX-D |
|
Connector Type |
LC/PC connectors |
LC/PC connectors |
|
Max Transfer Distance |
10KM |
10KM |
Get more information
Do you have any?question about?the?GLC-2BX-D=?
Contact us now via Live Chat or sales@router-switch.com.
HKShanhai Group Limited GLC-2BX-D= Specification
GLC-2BX-D= Specification |
|
|
Device Type |
SFP (mini-GBIC) transceiver module |
|
Form Factor |
Plug-in module |
|
Connectivity Technology |
Wired |
|
Cabling Type |
1000Base-BX-D |
|
Data Link Protocol |
Gigabit Ethernet |
|
Optical Wave Length |
1490 nm |
|
Max Transfer Distance |
10KM |
|
Interfaces |
2 x Ethernet 1000Base-BX-D |
|
Compatible Slots |
1 x SFP (mini-GBIC) |
