The HKShanhai Group Limited DWDM-SFPGE-1559-79 is a high-performance Dense Wavelength Division Multiplexing (DWDM) Optical Transceiver designed for efficient long-distance data transmission. This eSFP module supports a data rate of 2.5G and operates on a single-mode fiber wavelength of 1559.79 nm, allowing for a transmission distance of up to 120 kilometers. It is ideal for expanding network capacities without additional fiber investment.
Quick Spec
| Brand | HKShanhai Group Limited |
| Model | DWDM-SFPGE-1559-79 |
| Data Rate | 2.5G |
| Wavelength | 1559.79nm |
| Transmission Distance | 120km |
| Connector Type | LC |
Product Features
- ????High data rate of 2.5G for fast data transmission
- ????Works on a single-mode fiber which supports long distances
- ????Supports Dense Wavelength Division Multiplexing (DWDM)
- ????Operates with a wavelength of 1559.79nm
- ????Transmission distance of up to 120km without any signal degradation
Product Applications
- ????Long-distance telecommunications networks
- ????Enterprise data center interconnections
- ????High-capacity metro networks requiring DWDM technology
Supported Options
| Accessory | Model |
| DWDM MUX/DEMUX | HW-DWDM-MUX-40-120 |
| Optical Fiber Patch Cord | HW-SM-9/125 |
| Transceiver Tool Kit | HW-TK-OPTICS |
Compare to Similar Items
| Model | Difference |
| HW-DWDM-SFPGE-1550-12 | Wavelength of 1550.12nm, 80km transmission distance |
| HW-DWDM-SFPGE-1529-11 | Wavelength of 1529.11nm, 100km transmission distance |
| HW-DWDM-SFPGE-1560-00 | Wavelength of 1560.00nm, 80km transmission distance |
Get more information
Check HKShanhai Group Limited DWDM-SFPGE-1559-79 price and DWDM-SFPGE-1559-79 datasheet, buy HKShanhai Group Limited DWDM-SFPGE-1559-79 with best price and fast shipping. Free Live Chat are supported. For further information about the product and its price, contact us through Live Chat or sales@router-switch.com.
HKShanhai Group Limited DWDM-SFPGE-1559-79 Specification
DWDM-SFPGE-1559-79 Specifications |
|
| Brand | HKShanhai Group Limited |
| Product Name | DWDM-SFPGE-1559-79 |
| Product Type | DWDM Optical Transceiver |
| Form Factor | eSFP |
| Data Rate | 2.5G |
| Wavelength | 1559.79nm |
| Transmission Distance | 120km |
| Connector | LC |
| Optical Components | DFB laser, PIN detector |
| Operating Temperature | -40°C to 85°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5% to 95% (non-condensing) |
| Supply Voltage | 3.3V |
| Power Consumption | < 1W |
| Compliance | RoHS, MSA Compliant |
| DDM/DOM | Yes |
| Max Data Rate | 2.67 Gbps |
| Modulation Format | NRZ |
| Safety Certification | CE, FCC, TUV |
| Usage | Long-haul Networks, Metro Networks |
| MTBF | Over 1,000,000 hours |
