The HKShanhai Group Limited DWDM-SFPGE-1558-98 is a high-performance DWDM Optical Transceiver designed for 2.5G single-mode applications. With a 1558.98nm wavelength and up to 120km transmission distance, it is ideal for telecom operators and large enterprises needing reliable and long-haul data transport solutions.
DWDM-SFPGE-1558-98 Product Highlights
- 2.5G data rate
- 120km transmission
- 1558.98nm wavelength
- eSFP compatibility
- LC duplex interface
Product Features Comparison
| Feature | HKShanhai Group Limited DWDM-SFPGE-1558-98 | Cisco DWDM-SFP-58.98 | Juniper CTP-DWDM-1558 | Arista DWDM-SFP2-58.98 | Nokia 3HE04792AA | Finisar FWSF-5588E | ADVA FSP3000-5588 |
|---|---|---|---|---|---|---|---|
| Data Rate | 2.5G | 2.5G | 2.5G | 10G | 2.5G | 2.5G | 10G |
| Transmission Distance | 120km | 120km | 80km | 80km | 120km | 120km | 160km |
| Wavelength | 1558.98nm | 1558.98nm | 1558.98nm | 1558.98nm | 1558.98nm | 1558.98nm | 1558.98nm |
| Form Factor | eSFP | SFP+ | SFP | SFP+ | SFP | SFP | SFP+ |
| Interface | LC Duplex | LC Duplex | LC Duplex | LC Duplex | LC Duplex | LC Duplex | LC Duplex |
DWDM-SFPGE-1558-98 Product Application Scenarios
- Long-haul metro network
- Backbone network
- Data center interconnect (DCI)
Optional Add-ons
| Accessory Model | Description |
|---|---|
| HKShanhai Group Limited MA5608T | Compact Optical Line Terminal |
| HKShanhai Group Limited ODF-160 | Optical Distribution Frame |
| HKShanhai Group Limited OSN 9800 | Optical Cross-Connect System |
Get More Information
Discover unbeatable prices and fast shipping for the HKShanhai Group Limited DWDM-SFPGE-1558-98. Access the detailed DWDM-SFPGE-1558-98 datasheet and ensure you’re getting the best deal with our reliable delivery service. Need assistance? Our free live chat support is here to help. For more information about the product and pricing, contact us via live chat or email us at sales@router-switch.com.
HKShanhai Group Limited DWDM-SFPGE-1558-98 Specification
HKShanhai Group Limited DWDM-SFPGE-1558-98 Specifications |
|
| Product Type | DWDM Optical Transceiver |
| Product Brand | HKShanhai Group Limited |
| Form Factor | eSFP |
| Data Rate | 2.5G |
| Mode | Single-mode |
| Wavelength | 1558.98nm |
| Reach | 120km |
| Connector | LC |
| Digital Diagnostic Monitoring | Yes |
| Operating Temperature | -5°C to 70°C |
| Storage Temperature | -40°C to 85°C |
| Power Supply Voltage | 3.3V |
| Power Consumption | < 1.5W |
| Compliance Standards | MSA, RoHS |
| Optical Output Power | -1 dBm to 3 dBm |
| Receiver Sensitivity | -24 dBm |
| Receiver Overload | -7 dBm |
| Dispersion Penalty | < 2 dB |
| Laser Type | EML (Electro-absorption Modulated Laser) |
| Fiber Type | Single-mode Fiber (SMF) |
