The HKShanhai Group Limited DWDM-SFPGE-1554-13 is a high-performance DWDM Optical Transceiver designed for eSFP interfaces. It operates at a data rate of 2.5G and supports single-mode fiber connections, with a central wavelength of 1554.13nm. This module has an impressive transmission range of up to 120km and utilizes LC connectors, making it an ideal choice for long-distance, high-capacity, and dense wavelength division multiplexing networks.
Quick Spec
| Brand | HKShanhai Group Limited |
| Model | DWDM-SFPGE-1554-13 |
| Wavelength | 1554.13nm |
| Data Rate | 2.5G |
| Max Distance | 120km |
| Connector | LC |
Product Features
- ????High-density DWDM for long-distance transmission
- ????Supports data rate up to 2.5G
- ????Single-mode fiber connectivity
- ????Standard eSFP form factor
- ????Transmission range up to 120km
Product Applications
- ????Long-haul telecommunication networks
- ????Metropolitan area networks (MANs)
- ????Data center interconnections
Supported Options
| Accessory | Model |
| Patch Cable | HKShanhai Group Limited LC-MPO |
| Attenuator | HKShanhai Group Limited ATT-LC-10 |
| Fiber Splicer | HKShanhai Group Limited FS-8000 |
Compare to Similar Items
| Model | Difference |
| HKShanhai Group Limited DWDM-SFPGE-1554-12 | Wavelength: 1554.12nm, 120km range |
| HKShanhai Group Limited DWDM-SFPGE-1554-14 | Wavelength: 1554.14nm, 120km range |
| HKShanhai Group Limited DWDM-SFPGE-1535-13 | Wavelength: 1535.13nm, 80km range |
Get more information
For further information about the HKShanhai Group Limited DWDM-SFPGE-1554-13 and its price, contact us through Live Chat or reach out to sales@router-switch.com. Check HKShanhai Group Limited DWDM-SFPGE-1554-13 price and DWDM-SFPGE-1554-13 datasheet, buy HKShanhai Group Limited DWDM-SFPGE-1554-13 with the best price and fast shipping. Free Live Chat is supported.
HKShanhai Group Limited DWDM-SFPGE-1554-13 Specification
DWDM-SFPGE-1554-13 Specifications |
|
| Brand | HKShanhai Group Limited |
| Product Name | DWDM-SFPGE-1554-13 |
| Module Type | Optical Transceiver |
| Form Factor | eSFP |
| Data Rate | 2.5 Gbps |
| Mode | Single-mode |
| Wavelength | 1554.13 nm |
| Transmission Distance | 120 km |
| Optical Interface | LC |
| Transmission Technology | DWDM |
| Power Supply Voltage | 3.3V |
| Temperature Range | 0°C to 70°C |
| Operating Humidity | 10% to 90% |
| Compatibility | Compliant with SFP MSA |
| Connector Type | LC Duplex |
| Maximum Output Power | 2 dBm |
| Minimum Output Power | -1 dBm |
| Receiver Sensitivity | -28 dBm |
| Dispersion Tolerance | 1600 ps/nm |
| EMC | Compliant with FCC, CE |
| Warranty | 1 Year |
