The HKShanhai Group Limited DWDM-SFPGE-1553-33 is a sophisticated DWDM Optical Transceiver designed for high-speed data transmission and long-distance connectivity. This enhanced Small Form-factor Pluggable (eSFP) module operates at a frequency of 1553.33nm and can support single-mode fiber connections up to 120km. With a transmission rate of 2.5 gigabits per second, it is ideal for maximizing network efficiency and performance.
Quick Spec
| Data Rate | 2.5G |
| Wavelength | 1553.33nm |
| Fiber Type | Single-mode |
| Transmission Distance | 120km |
| Connector | LC |
Product Features
- High-speed data transfer rate of up to 2.5G
- DWDM technology for optimal wavelength management
- Supports long-distance transmission up to 120km
- Compact enhanced Small Form-factor Pluggable (eSFP) design
- Compatible with single-mode fiber and LC connectors
Product Applications
- High-speed core network connections over long distances
- Metropolitan Area Networks (MAN) requiring extended reach
- Data Center Interconnections (DCI) demanding high bandwidth and low latency
Supported Options
| Patch Cable | PC-LC-10M-OS2 |
| Fiber Attenuator | ATT-10DB-LC |
| Optical Power Meter | PM-205 |
Compare to Similar Items
| HKShanhai Group Limited DWDM-SFPGE-1530-33 | Different wavelength: 1530.33nm, shorter supported distance: 100km |
| HKShanhai Group Limited DWDM-SFPGE-1560-33 | Different wavelength: 1560.33nm, same distance: 120km |
| Cisco DWDM-SFP-1470 | Different brand, wavelength: 1470nm, shorter distance: 80km |
Get more information
Contact us through Live Chat or sales@router-switch.com for further information about the HKShanhai Group Limited DWDM-SFPGE-1553-33 and its price. Check “HKShanhai Group Limited DWDM-SFPGE-1553-33” price and “DWDM-SFPGE-1553-33 datasheet,” buy “HKShanhai Group Limited DWDM-SFPGE-1553-33 Module” with the best price and fast shipping. Free Live Chat is supported.
HKShanhai Group Limited DWDM-SFPGE-1553-33 Specification
DWDM-SFPGE-1553-33 Specifications |
|
| Brand | HKShanhai Group Limited |
| Model Name | DWDM-SFPGE-1553-33 |
| Product Type | DWDM Optical Transceiver |
| Form Factor | eSFP |
| Data Rate | 2.5G |
| Wavelength | 1553.33nm |
| Distance | 120km |
| Connector Type | LC |
| Transmission Media | Single-mode |
| Compatibility | Standard SFP ports |
| Output Power | 0dBm to +5dBm |
| Receiver Sensitivity | -28dBm |
| Protocols | SONET, SDH, Ethernet |
| Temperature Range | -40°C to 85°C |
| Power Supply Voltage | 3.3V |
| Power Consumption | <1.5W |
| MTP Compatibility | No |
| EMI Shielding | Yes |
| Hot Swappable | Yes |
| Digital Diagnostics | Yes |
| Compliance | RoHS, TUV, FCC, CE |
