The HKShanhai Group Limited DWDM-SFPGE-1552-52 is a high-performance DWDM Optical Transceiver designed for extended reach in telecommunication networks. With eSFP form factor, this 2.5G single-mode module operates at a wavelength of 1552.52nm and supports distances up to 120km. The module is equipped with an LC connector, making it a reliable choice for demanding network environments.
Quick Spec
| Brand | HKShanhai Group Limited |
| Model | DWDM-SFPGE-1552-52 |
| Form Factor | eSFP |
| Wavelength | 1552.52nm |
| Range | 120km |
| Connector | LC |
Product Features
- Supports Dense Wavelength Division Multiplexing (DWDM)
- 2.5 Gbps data transfer rate
- Single-mode fiber for long-distance communication up to 120km
- Comes in an enhanced Small Form-factor Pluggable (eSFP) package
- High stability with a wavelength of 1552.52nm
Product Applications
- Ideal for long-distance telecommunication transmission in metropolitan area networks (MANs)
- Suitable for enhancing bandwidth capacity in dense urban network settings
- Useful in backbone network systems requiring high-speed data transfer over long distances
Supported Options
| Accessory | Model |
| LC Duplex Patch Cable | PC-LC-1M |
| Fiber Optic Attenuator | FOA-5DB |
| Cleaning Kit | CK-F9 |
Compare to Similar Items
| Model | Differences |
| DWDM-SFPGE-1553-33 | Different wavelength (1553.33nm) |
| DWDM-SFPGE-1548-51 | Shorter distance (80km) |
| DWDM-SFPGE-1560-61 | Higher wavelength (1560.61nm) |
Get more information
For further information about the HKShanhai Group Limited DWDM-SFPGE-1552-52 and its price, including the HKShanhai Group Limited DWDM-SFPGE-1552-52 datasheet, contact us through Live Chat or at sales@router-switch.com. Check HKShanhai Group Limited DWDM-SFPGE-1552-52 price and DWDM-SFPGE-1552-52 datasheet, buy HKShanhai Group Limited DWDM-SFPGE-1552-52 module with the best price and fast shipping. Free Live Chat is supported.
HKShanhai Group Limited DWDM-SFPGE-1552-52 Specification
DWDM-SFPGE-1552-52 Specifications |
|
| Brand | HKShanhai Group Limited |
| Model | DWDM-SFPGE-1552-52 |
| Product Type | DWDM Optical Transceiver |
| Form Factor | eSFP |
| Data Rate | 2.5 Gbps |
| Wavelength | 1552.52 nm |
| Distance | 120 km |
| Optical Components | Single-mode Module |
| Connector Type | LC |
| Temperature Range | -40°C to 85°C |
| Hot Swappable | Yes |
| Compliance | DWDM MSA |
| Power Consumption | 1.5W |
| Digital Diagnostics | Yes |
| Receiver Sensitivity | -24dBm |
| Transmitter Power | -1 to +3dBm |
| Bit Error Rate (BER) | 1×10^(-12) |
| Protocols | SONET, SDH, Ethernet |
| Warranty | 1 Year |
| Certification | CE, FCC, RoHS |
