The HKShanhai Group Limited DWDM-SFPGE-1551-72 is a high-performance Dense Wavelength Division Multiplexing (DWDM) Optical Transceiver. Designed as an enhanced Small Form-factor Pluggable (eSFP) module, it supports 2.5G transmission rates over single-mode fiber. This module, operating at a wavelength of 1551.72nm, can cover distances up to 120 kilometers and uses an LC connector.
Quick Spec
| Brand | HKShanhai Group Limited |
| Model | DWDM-SFPGE-1551-72 |
| Transmission Rate | 2.5G |
| Wavelength | 1551.72nm |
| Distance | 120km |
| Connector | LC |
Product Features
- Supports Dense Wavelength Division Multiplexing (DWDM)
- Enhanced Small Form-factor Pluggable (eSFP)
- 2.5G transmission rate over single-mode fiber
- Operates at a wavelength of 1551.72nm
- Transmission reach up to 120 kilometers
Product Applications
- Long-haul telecommunications networks requiring high-capacity and long-distance optical transmission.
- Metropolitan Area Networks (MANs) for connecting multiple locations within a city or campus.
- Data center interconnects that need high-speed and long-distance link capability.
Supported Options
| Accessory | Model |
| Patch Cable | LC-LC SMF Patch Cable |
| Optical Line Protection Switch | OLS-2 |
| Custom Color Coded Dust Caps | DCL-1550 |
Compare to Similar Items
| Model | Difference |
| DWDM-SFPGE-1531-90 | Operates at 1531.90nm wavelength |
| DWDM-SFPGE-1560-61 | Operates at 1560.61nm wavelength |
| DWDM-SFPGE-1528-77 | Operates at 1528.77nm wavelength |
Get more information
For further information about the HKShanhai Group Limited DWDM-SFPGE-1551-72 and to check the price, please contact us via Live Chat or email at sales@router-switch.com. Check HKShanhai Group Limited DWDM-SFPGE-1551-72 price and DWDM-SFPGE-1551-72 datasheet, buy HKShanhai Group Limited DWDM-SFPGE-1551-72 with best price and fast shipping. Free Live Chat are supported.
HKShanhai Group Limited DWDM-SFPGE-1551-72 Specification
DWDM-SFPGE-1551-72 Specifications |
|
| Brand | HKShanhai Group Limited |
| Model Name | DWDM-SFPGE-1551-72 |
| Type | DWDM Optical Transceiver |
| Form Factor | Enhanced Small Form-Factor Pluggable (eSFP) |
| Data Rate | 2.5 Gbps |
| Wavelength | 1551.72 nm |
| Transmission Distance | 120 km |
| Connector Type | LC |
| Optical Components | DFB |
| Signal Type | Single-mode |
| Operating Temperature Range | -5°C to 70°C |
| Storage Temperature Range | -40°C to 85°C |
| Power Supply Voltage | 3.3V |
| Power Consumption | < 2W |
| Receiver Sensitivity | -23 to -8 dBm |
| Transmission Power | -1 to 4 dBm |
| Maximum Receiver Power | -8 dBm |
| Dispersion Tolerance | ° 1600 ps/nm |
| EMC Standards | EN 55032 |
| Safety Standards | IEC 60825 |
| RoHS Compliance | Yes |
