The HKShanhai Group Limited DWDM-SFPGE-1550-12 is a high-performance DWDM Optical Transceiver designed for extended-range communication up to 120km. This enhanced small form-factor pluggable (eSFP) module supports a data rate of 2.5G over single-mode fiber with a wavelength of 1550.12nm, ensuring efficient and reliable connectivity for your advanced networking needs.
Quick Spec
| Product Type | DWDM Optical Transceiver |
| Form Factor | eSFP |
| Data Rate | 2.5G |
| Wavelength | 1550.12nm |
| Distance | 120km |
Product Features
- ??High-performance DWDM technology for long-haul communication.
- ??Supports a data rate of up to 2.5G.
- ??Designed for use with single-mode fiber (SMF).
- ??LC connector type for easy installation and maintenance.
- ??Extended reach of up to 120km, reducing the need for additional equipment.
Product Applications
- ??Telecom operators can use this transceiver for efficient long-distance data transmission on DWDM networks, resulting in enhanced network performance and reduced latency.
- ??Enterprises can deploy this module to interconnect geographically dispersed data centers, ensuring high-speed and reliable data transfer.
- ??Service providers can benefit from this transceiver in deploying high-capacity metro networks to handle increased data traffic and broadband services.
Supported Options
| Accessory | Model |
| LC to FC Patch Cord | PCLF-3M |
| Optical Power Meter | OPM-15 |
| Fiber Optic Cleaning Kit | FCLK-01 |
Compare to Similar Items
| Feature | HKShanhai Group Limited DWDM-SFPGE-1550-12 | HKShanhai Group Limited DWDM-SFPGE-1545-05 | Cisco DWDM-SFP10G-42.94 |
| Data Rate | 2.5G | 2.5G | 10G |
| Wavelength | 1550.12nm | 1545.05nm | 1542.94nm |
| Distance | 120km | 100km | 80km |
| Form Factor | eSFP | eSFP | SFP+ |
| Connector | LC | LC | LC |
Get more information
For further details about the HKShanhai Group Limited DWDM-SFPGE-1550-12, please get in touch via Live Chat or email us at sales@router-switch.com. Check HKShanhai Group Limited DWDM-SFPGE-1550-12 price and DWDM-SFPGE-1550-12 datasheet, buy HKShanhai Group Limited DWDM-SFPGE-1550-12 with the best price and fast shipping. Free Live Chat support is available for your convenience.
HKShanhai Group Limited DWDM-SFPGE-1550-12 Specification
DWDM-SFPGE-1550-12 Specifications |
|
| Brand | HKShanhai Group Limited |
| Model | DWDM-SFPGE-1550-12 |
| Type | DWDM Optical Transceiver |
| Form Factor | eSFP |
| Data Rate | 2.5G |
| Interface | LC |
| Mode Type | Single-mode |
| Wavelength | 1550.12 nm |
| Transmission Distance | 120 km |
| Output Power | 0 ~ 4 dBm |
| Receiver Sensitivity | -20 dBm |
| Extinction Ratio | 9 dB |
| Power Consumption | < 1.5 W |
| Temperature Range | 0°C to 70°C (32°F to 158°F) |
| Dimensions | 56.5 x 14.0 x 8.5 mm |
| Compatibility | Universal Compatibility with SFP Ports |
| MTBF | 1 Million Hours |
| Hot Swappable | Yes |
| Regulatory Compliance | RoHS, CE |
| Application | Telecommunications, Data Center |
| Warranty | 1 Year |
