The HKShanhai Group Limited DWDM-SFPGE-1548-51 is a high-performance Dense Wavelength Division Multiplexing (DWDM) Optical Transceiver designed for superior network connectivity. This enhanced Small Form-factor Pluggable (eSFP) transceiver supports 2.5G data rates over long distances up to 120 km using single-mode fiber. Operating at the 1548.51nm wavelength, it ensures reliable and efficient data transmission, making it an ideal solution for high-capacity metropolitan and long-haul networks.
Quick Spec
| Brand | HKShanhai Group Limited |
| Product Name | DWDM-SFPGE-1548-51 |
| Type | DWDM Optical Transceiver |
| Format | eSFP |
| Data Rate | 2.5G |
| Fiber Type | Single-mode |
| Wavelength | 1548.51nm |
| Distance | 120km |
| Connector | LC |
Product Features
- High-capacity DWDM technology for efficient bandwidth utilization
- Extended reach of up to 120 km
- Compact eSFP form factor for scalable deployment
- Operates at a precise 1548.51nm wavelength
- Supports 2.5G data rate for dependable high-speed connections
Product Applications
- Metropolitan Area Networks (MANs) requiring high data throughput
- Long-distance telecommunication networks
- High-capacity data centers needing reliable, long-distance connectivity
Supported Options
| Accessory | Model |
| Mounting Bracket | BRKT-ESFP |
| Fiber Patch Cable | FPC-SM-LC-5M |
| Dust Cover | DC-SFP-LC |
Compare to Similar Items
| Model | Differences |
| DWDM-SFPGE-1530-79 | Different wavelength (1530.79nm) |
| DWDM-SFPGE-1551-72 | Different wavelength (1551.72nm) |
| DWDM-SFPGE-1528-33 | Different wavelength (1528.33nm) |
Get more information
Check HKShanhai Group Limited DWDM-SFPGE-1548-51 price and DWDM-SFPGE-1548-51 datasheet, buy HKShanhai Group Limited DWDM-SFPGE-1548-51 with best price and fast shipping. Free Live Chat are supported. Contact us through Live Chat or sales@router-switch.com for further information about the product and its price.
HKShanhai Group Limited DWDM-SFPGE-1548-51 Specification
DWDM-SFPGE-1548-51 Specifications |
|
| Brand | HKShanhai Group Limited |
| Product Name | DWDM-SFPGE-1548-51 |
| Form Factor | eSFP (Enhanced Small Form-factor Pluggable) |
| Data Rate | 2.5 Gbps |
| Wavelength | 1548.51 nm |
| Max Distance | 120 km |
| Optical Components | DFB Laser, PIN Photodiode |
| Connector | LC |
| Temperature Range | 0°C to 70°C (Standard) |
| Transmission Media | Single-mode Fiber (SMF) |
| Power Supply | 3.3V |
| Max Power Consumption | 1.5W |
| Regulatory Compliance | RoHS, CE, FCC |
| MTBF | Greater than 1,000,000 hours |
| Digital Diagnostic Monitoring | Yes |
| Fiber Mode | Single-mode |
| Compatibility | IEEE 802.3ah |
| TX Power | 0 to +5 dBm |
| RX Sensitivity | -28 dBm |
| Return Loss | Greater than 20 dB |
| Dispersion Penalty | Less than 2 dB |
