The HKShanhai Group Limited DWDM-SFPGE-1546-12 is a high-performance, Dense Wavelength Division Multiplexing (DWDM) optical transceiver. Designed as an eSFP 2.5G single-mode module operating at 1546.12nm wavelength, it supports up to 120km reach, providing efficient and reliable data transmission. This module comes with an LC connector, making it a perfect fit for long-distance communication needs.
Quick Spec
| Brand | HKShanhai Group Limited |
| Model | DWDM-SFPGE-1546-12 |
| Wavelength | 1546.12nm |
| Data Rate | 2.5G |
| Reach | 120km |
| Connector | LC |
Product Features
- High-density DWDM technology
- Extended reach up to 120km
- Low power consumption
- Excellent reliability and stability
- Easy integration with existing networks
Product Applications
- Long-haul telecommunications
- Metro Ethernet networks
- Data Center Interconnect (DCI)
Supported Options
| Accessory | Model |
| Optical Fiber Patch Cable | HKShanhai Group Limited LC-SM-5 |
| DWDM MUX/DEMUX | HKShanhai Group Limited MUX-16 |
| SFP+ Adapter | HKShanhai Group Limited SFP+ADP |
Compare to Similar Items
| Model | Difference |
| DWDM-SFPGE-1540-12 | Wavelength: 1540.12nm |
| DWDM-SFPGE-1550-12 | Wavelength: 1550.12nm |
| DWDM-SFPGE-1560-12 | Wavelength: 1560.12nm |
Get more information
Check HKShanhai Group Limited DWDM-SFPGE-1546-12 price and DWDM-SFPGE-1546-12 datasheet, buy HKShanhai Group Limited DWDM-SFPGE-1546-12 with best price and fast shipping. Free Live Chat are supported. For more detailed information about the product and pricing, please contact us through Live Chat or email us at sales@router-switch.com.
HKShanhai Group Limited DWDM-SFPGE-1546-12 Specification
DWDM-SFPGE-1546-12 Specifications |
|
| Brand | HKShanhai Group Limited |
| Product Name | DWDM-SFPGE-1546-12 |
| Type | DWDM Optical Transceiver |
| Module Type | eSFP |
| Data Rate | 2.5G |
| Mode | Single-mode |
| Wavelength | 1546.12nm |
| Transmission Distance | 120km |
| Connector | LC |
| Temperature Range | -5°C to 70°C |
| Power Supply | 3.3V |
| Compliance | RoHS |
| Tx Power | 0 to 4 dBm |
| Receiver Sensitivity | -24 dBm |
| Extinction Ratio | 9 dB |
| DDM/DOM | Yes |
| Electrical Interface | LC Connector |
| Modulation Format | NRZ |
| MTBF | More than 1,000,000 hours |
| Electrical Power Consumption | ° 1.5W |
| Laser | DFB Laser |
