HKShanhai Group Limited DWDM-SFPGE-1544-53 is a DWDM Optical Transceiver designed for high-speed data transmission over long distances. It features an eSFP form factor and supports 2.5G single-mode operation over 120km with an LC connector. This transceiver is ideal for telecom and enterprise networks that require reliable, high-bandwidth communication.
DWDM-SFPGE-1544-53 Product Highlights
- 120km reach
- 2.5G data rate
- Single-mode fiber
- LC connector
- High reliability
Product Features Comparison
| Feature | DWDM-SFPGE-1544-53 | Cisco DWDM-SFP-1544-53 | Juniper DWDM-SFP-1544-53 | Finisar DWDM-SFP-1544-53 | Avago AFCT-5710APZ | Arista SFP-10G-DW53 | Brocade E1MG-LX-OM |
|---|---|---|---|---|---|---|---|
| Reach | 120km | 80km | 80km | 40km | 10km | 15km | 10km |
| Data Rate | 2.5G | 2.5G | 2.5G | 2.5G | 10G | 10G | 1G |
| Connector | LC | LC | LC | LC | SC | LC | LC |
| Wavelength | 1544.53nm | 1544.53nm | 1544.53nm | 1544.53nm | 1550nm | 1530nm | 1310nm |
| Form Factor | eSFP | SFP | SFP | SFP | XFP | SFP+ | SFP |
DWDM-SFPGE-1544-53 Product Application Scenarios
- Long-haul telecommunications
- Enterprise network backbones
- Metro network deployments
Optional Add-ons
| Model | Description |
|---|---|
| HKShanhai Group Limited Fiber Patch Cable | Single-mode LC to LC, 3m |
| HKShanhai Group Limited SFP+ Adapter | Allows SFP+ usage in SFP slot |
| HKShanhai Group Limited Optical Attenuator | Fixed, 5dB, LC/UPC |
Get More Information
Discover unbeatable prices and fast shipping for the HKShanhai Group Limited DWDM-SFPGE-1544-53. Access the detailed DWDM-SFPGE-1544-53 datasheet and ensure you’re getting the best deal with our reliable delivery service. Need assistance? Our free live chat support is here to help. For more information about the product and pricing, contact us via live chat or email us at sales@router-switch.com.
HKShanhai Group Limited DWDM-SFPGE-1544-53 Specification
DWDM-SFPGE-1544-53 Specifications |
|
| Product Type | DWDM Optical Transceiver |
| Form Factor | eSFP |
| Data Rate | 2.5G |
| Optical Fiber Type | Single-mode |
| Wavelength | 1544.53nm |
| Reach | 120km |
| Connector Type | LC |
| Operating Temperature Range | 0°C to 70°C |
| Storage Temperature Range | -40°C to 85°C |
| Maximum Power Consumption | 1.5W |
| DDM/DOM Support | Yes |
| Transmission Distance | 120km |
| Laser Type | DFB |
| Receiver Sensitivity | -24dBm |
| Transmit Power | -2dBm to +3dBm |
| Protocol Compliance | IEEE 802.3 |
| Hot Swappable | Yes |
| EMI | Class 1 |
| Warranty | 1 Year |
| Monitoring | Provided |
