HKShanhai Group Limited DWDM-SFPGE-1542-94 is a DWDM Optical Transceiver aimed at providing high-speed 2.5G data transmission over Single-mode fiber for up to 120km. Suitable for network engineers and procurement teams, this device is ideal for long-distance data transport and telecommunications.
DWDM-SFPGE-1542-94 Product Highlights
- High data rate: 2.5G
- Single-mode compatibility
- Long reach: 120km
- Specific wavelength: 1542.94nm
- eSFP form factor
Product Features Comparison
| Feature | DWDM-SFPGE-1542-94 | DWDM-SFPGE-1550-92 | DWDM-SFPGE-1535-96 | DWDM-SFPGE-1560-92 | CWDM-SFPGE-1570-95 | DWDM-SFPGE-1580-91 | DWDM-SFPGE-1520-95 |
|---|---|---|---|---|---|---|---|
| Wavelength (nm) | 1542.94 | 1550.92 | 1535.96 | 1560.92 | 1570.95 | 1580.91 | 1520.95 |
| Data Rate | 2.5G | 2.5G | 2.5G | 2.5G | 2.5G | 2.5G | 2.5G |
| Transmission Distance | 120km | 120km | 120km | 120km | 100km | 120km | 120km |
| Fiber Type | Single-mode | Single-mode | Single-mode | Single-mode | Single-mode | Single-mode | Single-mode |
| Form Factor | eSFP | eSFP | eSFP | eSFP | eSFP | eSFP | eSFP |
DWDM-SFPGE-1542-94 Product Application Scenarios
- Long-distance data transport
- Telecommunications networks
- ISP backbone deployment
Optional Add-ons
| Model | Description |
|---|---|
| LC-LC-SM-3M | LC to LC Single-mode Patch Cord, 3m |
| SFP-Adapter | SFP Slot Adapter |
| ATSPN-1001FC | SFP Dust Cover |
Get More Information
Discover unbeatable prices and fast shipping for the HKShanhai Group Limited DWDM-SFPGE-1542-94. Access the detailed DWDM-SFPGE-1542-94 datasheet and ensure you’re getting the best deal with our reliable delivery service. Need assistance? Our free live chat support is here to help. For more information about the product and pricing, contact us via live chat or email us at sales@router-switch.com.
HKShanhai Group Limited DWDM-SFPGE-1542-94 Specification
HKShanhai Group Limited DWDM-SFPGE-1542-94 Specifications |
|
| Brand | HKShanhai Group Limited |
| Model | DWDM-SFPGE-1542-94 |
| Type | DWDM Optical Transceiver |
| Form Factor | eSFP |
| Data Rate | 2.5G |
| Fiber Type | Single-mode |
| Wavelength | 1542.94nm |
| Max Transmission Distance | 120km |
| Connector Type | LC |
| Operating Temperature | 0°C to 70°C |
| Storage Temperature | -40°C to 85°C |
| Transmission Power | -1 to +4 dBm |
| Receiver Sensitivity | -27 dBm |
| Power Consumption | Less than 1.5W |
| Protocol | ITU-T G.694.1 |
| Compliance | RoHS |
| Dimensions | 56.5 mm x 13.5 mm x 8.5 mm |
| Laser Type | DFB (Distributed Feedback) |
| EMI Immunity | High |
| Warranty | 3 years |
