The HKShanhai Group Limited DWDM-SFPGE-1540-56 is an advanced DWDM Optical Transceiver designed for single-mode fiber connections. Offering high performance with a 2.5G data rate, this module enables extended reach of up to 120km. Ideal for enterprise and service provider networks seeking power-efficient, stable, and extensive wavelength connectivity.
DWDM-SFPGE-1540-56 Product Highlights
- 2.5G data rate
- Single-mode module
- 120km reach
- LC connector
- Highly reliable
DWDM-SFPGE-1540-56 Product Comparison
| Feature | DWDM-SFPGE-1540-56 | Cisco SFP-10G-DWDM | Juniper CTP-SFP-1GE | Finisar FTLX1671D3BCV-1 | Avago AFBR-709SMZ | Arista SFP-10G28D | Brocade E1MG-TX |
|---|---|---|---|---|---|---|---|
| Data Rate | 2.5G | 10G | 1G | 10G | 10G | 10G | 1G |
| Range | 120km | 80km | 40km | 100km | 80km | 100km | 100m |
| Mode | Single-mode | Single-mode | Single-mode | Single-mode | Single-mode | Single-mode | Multi-mode |
| Connector | LC | LC | LC | LC | LC | LC | RJ-45 |
| Wavelength | 1540.56nm | 1530nm~1565nm | 1270nm~1610nm | 1570nm | 1310nm/1550nm | 1547.72nm | 850nm |
| Temperature Range | 0°C to 70°C | 0°C to 70°C | -40°C to 85°C | 0°C to 70°C | 0°C to 70°C | 0°C to 70°C | 0°C to 70°C |
DWDM-SFPGE-1540-56 Product Application Scenarios
- Long-distance fiber optics
- Telecommunications networks
- Enterprise data centers
Optional Add-ons
| Model | Description |
|---|---|
| HKShanhai Group Limited FLS-40 | Fiber Line Simulator, 40km |
| Cisco ONS-SC+ | Optical Network Splitter, C-band |
| Juniper SFP-ACC | SFP+ Cable Assembly, 10G |
Get More Information
Discover unbeatable prices and fast shipping for the HKShanhai Group Limited DWDM-SFPGE-1540-56. Access the detailed DWDM-SFPGE-1540-56 datasheet and ensure you’re getting the best deal with our reliable delivery service. Need assistance? Our free live chat support is here to help. For more information about the product and pricing, contact us via live chat or email us at sales@router-switch.com.
HKShanhai Group Limited DWDM-SFPGE-1540-56 Specification
DWDM-SFPGE-1540-56 Specifications |
|
| Brand | HKShanhai Group Limited |
| Product Name | DWDM-SFPGE-1540-56 |
| Transceiver Type | DWDM Optical Transceiver |
| Form Factor | eSFP |
| Data Rate | 2.5G |
| Wavelength | 1540.56nm |
| Maximum Distance | 120km |
| Connector | LC |
| Fiber Type | Single-mode |
| Interface | LC Duplex |
| Operating Temperature Range | 0°C to 70°C |
| Storage Temperature Range | -40°C to 85°C |
| Power Supply Voltage | 3.3V |
| Power Consumption | <1.5W |
| Regulatory Compliance | RoHS, CE, FCC |
| EMC | CFR47 Part 15 Class B |
| Modulation Format | DPSK |
| Protocol Support | ITU-T G.694.1 |
| Transmission Distance | 120km |
| Receiver Sensitivity | -24dBm |
