The HKShanhai Group Limited DWDM-SFPGE-1537-40 is a high-performance DWDM optical transceiver module designed for seamless data transmission in long-distance networks. This enhanced small form-factor pluggable (eSFP) module operates at a wavelength of 1537.40nm and supports single-mode fiber to achieve a transmission distance of up to 120km. With a data rate of 2.5G, it is ideal for telecommunications and data center applications.
Quick Spec
| Brand | HKShanhai Group Limited |
| Model | DWDM-SFPGE-1537-40 |
| Data Rate | 2.5G |
| Wavelength | 1537.40nm |
| Transmission Distance | 120km |
| Connector | LC |
Product Features
- ??High data rate of 2.5G suitable for fast data transmission.
- ??Supports DWDM technology to maximize bandwidth efficiency.
- ??Extended reach of up to 120km for long-distance data links.
- ??Compact eSFP form factor for easy integration into compatible devices.
- ??Utilizes LC connectors for reliable and stable connectivity.
Product Applications
- ??Ideal for telecom operators to extend network coverage without compromising on performance.
- ??Suitable for data center interconnects requiring high data rates and long-distance transmission.
- ??Perfect for enterprise networks seeking efficient and reliable long-range data communication.
Supported Options
| Accessory | Model |
| Fiber Optic Patch Cable | OM3-LC-LC-1M |
| Optical Attenuator | AT-LC-10dB |
| SFP Dust Cover | SFPCover1 |
Compare to Similar Items
| Model | Difference |
| DWDM-SFPGE-1545-40 | Different wavelength (1545.32nm) |
| DWDM-SFPGE-1553-40 | Different wavelength (1553.72nm) |
| DWDM-SFPGE-1529-40 | Different wavelength (1529.55nm) |
Get more information
Check HKShanhai Group Limited DWDM-SFPGE-1537-40 price and DWDM-SFPGE-1537-40 datasheet, buy HKShanhai Group Limited DWDM-SFPGE-1537-40 with best price and fast shipping. Free Live Chat are supported.
HKShanhai Group Limited DWDM-SFPGE-1537-40 Specification
DWDM-SFPGE-1537-40 Specifications |
|
| Brand | HKShanhai Group Limited |
| Product Name | DWDM-SFPGE-1537-40 |
| Type | DWDM Optical Transceiver |
| Form Factor | eSFP |
| Data Rate | 2.5G |
| Wavelength | 1537.40nm |
| Maximum Distance | 120km |
| Connector Type | LC |
| Mode | Single-mode |
| Operating Temperature | -5°C to 70°C |
| Storage Temperature | -40°C to 85°C |
| Power Supply Voltage | 3.3V |
| Power Consumption | <2W |
| Transmission Medium | Optical Fiber |
| Compliance | RoHS, MSA Compliant |
| Reach | Long Haul |
| Optical Budget | 28dB |
| Receiver Sensitivity | -28dBm |
| Transmit Power | 0dBm to 5dBm |
| DDM/DOM | Supported |
| Application | Metro Network, DWDM Network |
