The HKShanhai Group Limited DWDM-SFPGE-1534-25 is a high-performance DWDM Optical Transceiver designed for use in demanding networking environments. This eSFP transceiver supports a data rate of 2.5G and operates on a single-mode fiber, making it ideal for long-distance connections up to 120km. The transceiver’s wavelength is set at 1534.25nm, and it features an LC connector, ensuring seamless integration into existing network infrastructure.
Quick Spec
| Brand | HKShanhai Group Limited |
| Model | DWDM-SFPGE-1534-25 |
| Data Rate | 2.5G |
| Transmission Distance | 120km |
| Wavelength | 1534.25nm |
| Connector Type | LC |
Product Features
- ??High-performance 2.5G data rate for robust networking.
- ??Single-mode module supports long-distance transmission up to 120km.
- ??LC connector ensures reliable and stable connections.
- ??Operates at a specific wavelength of 1534.25nm for targeted network applications.
- ??DWDM technology enables efficient bandwidth utilization and network expansion.
Product Applications
- ??Long-haul telecommunications networks requiring high-performance data transmission.
- ??Metropolitan area networks (MAN) looking to extend connectivity across wide distances.
- ??Data center interconnects where high data rates and stable performance are necessary.
Supported Options
| Accessory | Model |
| DWDM Multiplexer/Demultiplexer Module | HU-MUX-40-CH |
| Transceiver Tester | HU-TEST-100G |
| Patch Cable | HU-ST-LC-09 |
Compare to Similar Items
| Model | Differences |
| DWDM-SFPGE-1528-25 | Operates at 1528.77nm wavelength. |
| DWDM-SFPGE-1531-25 | Operates at 1531.12nm wavelength. |
| DWDM-SFPGE-1537-25 | Operates at 1537.47nm wavelength. |
Get more information
Check HKShanhai Group Limited DWDM-SFPGE-1534-25 price and DWDM-SFPGE-1534-25 datasheet, buy HKShanhai Group Limited DWDM-SFPGE-1534-25 Transceiver with the best price and fast shipping. Free Live Chat are supported. For further information about the product and its price, please contact us through Live Chat or email at sales@router-switch.com.
HKShanhai Group Limited DWDM-SFPGE-1534-25 Specification
DWDM-SFPGE-1534-25 Specifications |
|
| Brand | HKShanhai Group Limited |
| Model | DWDM-SFPGE-1534-25 |
| Type | DWDM Optical Transceiver |
| Form Factor | eSFP |
| Data Rate | 2.5G |
| Wavelength | 1534.25nm |
| Distance | 120km |
| Connector Type | LC |
| Media Type | Single-mode Fiber |
| Operating Temperature | 0°C to 70°C |
| Storage Temperature | -40°C to 85°C |
| Power Supply Voltage | 3.3V |
| Max Power Consumption | 1.5W |
| Receiver Sensitivity | -24 dBm |
| Transmitter Output Power | 0 to +5 dBm |
| Extinction Ratio | 9 dB |
| DDM/DOM | Supported |
| Protocols | ITU-T G.694.1 |
| Compliance | RoHS6 |
| MTBF | 1,000,000 hours |
