The HKShanhai Group Limited DWDM-SFPGE-1530-33 is a highly efficient DWDM Optical Transceiver designed for long-distance communication. This eSFP, 2.5G, Single-mode Module operates at a wavelength of 1530.33nm and supports transmission distances up to 120km using an LC connector. It is ideal for a wide range of telecom applications, providing reliable and high-speed data transfer.
Quick Spec
| Brand | HKShanhai Group Limited |
| Model | DWDM-SFPGE-1530-33 |
| Wavelength | 1530.33nm |
| Transmission Distance | 120km |
| Connector | LC |
Product Features
- ??Dense Wavelength Division Multiplexing (DWDM) technology for efficient bandwidth utilization.
- ??Single-mode fiber support for long-distance transmission up to 120km.
- ??Operates at a high data rate of 2.5G for fast data transfer.
- ??LC connector type for secure and stable connections.
- ??Designed for high reliability and performance in telecom applications.
Product Applications
- ??Telecommunication networks involving long-haul data transmission.
- ??Data center interconnects needing high-speed, long-distance connectivity.
- ??Enterprise network backbones requiring robust and reliable communication links.
Supported Options
| Accessory Model | Description |
| LC-SM-10 | 10m LC Single-mode Fiber Cable |
| LC-Duplex-5 | 5m LC Duplex Fiber Patch Cable |
| DWDM-MUX-08 | 8-channel DWDM Mux/Demux Module |
Compare to Similar Items
| Model | Differences |
| HKShanhai Group Limited DWDM-SFPGE-1550-32 | Wavelength: 1550.32nm, Transmission Distance: 80km |
| HKShanhai Group Limited DWDM-SFPGE-1570-31 | Wavelength: 1570.31nm, Transmission Distance: 100km |
| HKShanhai Group Limited DWDM-SFPGE-1590-30 | Wavelength: 1590.30nm, Transmission Distance: 60km |
Get more information
For further information about the HKShanhai Group Limited DWDM-SFPGE-1530-33 and its price, contact us through Live Chat or at sales@router-switch.com. Check HKShanhai Group Limited DWDM-SFPGE-1530-33 price and DWDM-SFPGE-1530-33 datasheet, buy HKShanhai Group Limited DWDM-SFPGE-1530-33 with the best price and fast shipping. Free Live Chat support is available.
HKShanhai Group Limited DWDM-SFPGE-1530-33 Specification
DWDM-SFPGE-1530-33 Specifications |
|
| Brand | HKShanhai Group Limited |
| Product Name | DWDM-SFPGE-1530-33 |
| Form Factor | eSFP |
| Data Rate | 2.5 Gbps |
| Wavelength | 1530.33 nm |
| Reach | 120 km |
| Fiber Type | Single-mode |
| Connector | LC |
| Operating Temperature | 0°C to 70°C (32°F to 158°F) |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) |
| Manufacturer | HKShanhai Group Limited |
| Protocol | ITU-T G.694.1 |
| Interface | Hot Pluggable |
| Max Supply Current | 300 mA |
| Power Supply Voltage | 3.3 V |
| Sensitivity | -24 dBm |
| Transmit Power | -1 dBm to +4 dBm |
| Receiver Overload | -7 dBm |
| Digital Diagnostics | Yes |
| Compliance | RoHS |
